Chapter 9
Step 9: Fasten the brackets to the rear columns.
NOTE
The brackets serve to dampen vibration of the server chassis.
Line up the screws as shown below. The bracket should be in contact
with the foot protruding from the rear of the LPr chassis.
Finger-tighten four T25 Torx screws, two in each rear column,
through the flanges into the rack nuts.
Figure 9-13. Finger-Tighten the Brackets to the Rear Columns
Mounting the Server in the Rack
73
