HP NetRAID DIMM
Installation Guide for
HP NetServer LH 3000/3000r
and LH 6000/6000r
HP Part Number 5969-5909
Printed in November 1999

Advertising

   Related Manuals for HP D7171A - NetServer - LPr

   Summary of Contents for HP D7171A - NetServer - LPr

  • Page 1

    HP NetRAID DIMM Installation Guide for HP NetServer LH 3000/3000r and LH 6000/6000r HP Part Number 5969-5909 Printed in November 1999...

  • Page 2

    Hewlett-Packard shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.

  • Page 3: Audience Assumptions

    © Copyright 1999, Hewlett-Packard Company. Audience Assumptions The guide is for the person who installs, administers, and troubleshoots LAN servers. Hewlett-Packard Company assumes you are qualified in the servicing of computer equipment and trained in recognizing hazards in products with hazardous energy levels.

  • Page 5: Table Of Contents

    F. Replacing Cover 1 ..............12 G. Restarting the HP NetServer ..........13 Warranty and Support............... 15 Hardware Accessories Limited Warranty......... 15 Hewlett-Packard Hardware Accessories ........15 Third-Party Hardware Products ........... 17 HP Repair and Telephone Support..........17 Regulatory Information..............19...

  • Page 7: Introduction

    Introduction This guide describes upgrading HP NetRAID memory in HP NetServer LH 3000/3000r and LH 6000/6000r. HP NetRAID memory is required for integrated HP NetRAID operation. For more information about integrated HP NetRAID, refer to the Integrated HP NetRAID Controller Configuration Guide.

  • Page 9: Installing The Hp Netraid Dimm, Installation Overview

    Installing the HP NetRAID DIMM Installation Overview This guide lists the tools and procedure for upgrading the HP NetRAID DIMM in an HP NetServer LH 3000/3000r or LH 6000/6000r. CAUTION The HP NetRAID DIMM is sensitive to static electricity and can easily be damaged by improper handling.

  • Page 10: Tools You Need

    The following procedures are required to install the DIMM: A. Shutting Down and Disconnecting Power B. Removing Cover 1 C. Disconnecting the BBM, if present D. Replacing the DIMM E. Reconnecting the BBM, if present F. Replacing Cover 1 G. Restarting the HP NetServer Tools You Need The following materials are also required to install this upgrade: ®...

  • Page 11: Installation, A. Shutting Down And Disconnecting Power, B. Removing Cover 1

    Installation A. Shutting Down and Disconnecting Power Do the following to prepare for installation: 1. Bring down the NetServer’s operating system properly to make sure that cache memory has been flushed. 2. Turn the NetServer power off. 3. Disconnect the power cord(s). CAUTION Be sure the HP NetServer is turned off and disconnected from AC power before you remove or...

  • Page 12: C. Disconnecting The Bbm

    Cover 1 Cover 1 Pedestal Configuration Rack-Optimized Configuration Figure 1. Cover 1 and Status Screen Locations C. Disconnecting the BBM If a BBM is present, disconnect the BBM cable from the system backplane, as shown in Figure 2.

  • Page 13

    System Backplane Unplug cable Battery Backup Module (BBM) Figure 2. Disconnecting the BBM Cable (Shown for Pedestal Configuration)

  • Page 14: D. Replacing The Dimm

    D. Replacing the DIMM Replace the DIMM, as follows: 1. Remove the new DIMM from its anti-static container, handling the module by its ends; do not touch the pins. Lay it on an antistatic surface. 2. Locate the existing HP NetRAID DIMM in its socket on the I/O baseboard, which is shown in Figures 3 and 4.

  • Page 15

    HP NetRAID DIMM I/O Baseboard DIMM Socket Figure 3. I/O Baseboard in HP NetServer LH 3000 and LH 6000...

  • Page 16

    HP NetRAID DIMM Socket I/O Baseboard Figure 4. I/O Baseboard in HP NetServer LH 3000r and LH /6000r...

  • Page 17

    3. Simultaneously depress both retaining clips on the DIMM socket, which is shown in Figure 5. DIMM Notches Keys Retaining Clips Figure 5. Removing and Installing the DIMM in the Socket 4. Remove the existing DIMM from the socket. If you plan to keep the DIMM for another use, handle it by its ends;...

  • Page 18: E. Reconnecting The Bbm, F. Replacing Cover 1

    8. Insert the new DIMM carefully into the socket. The retaining clips will close automatically if it is inserted properly. CAUTION Do not rock the DIMM into place, but apply firm and even pressure directly downward. If the retaining clips do not close, remove the module and repeat Steps 5 through 8.

  • Page 19: G. Restarting The Hp Netserver

    G. Restarting the HP NetServer 1. Connect the power cords and all other external cables. 2. Turn on the HP NetServer, and verify that it starts properly. If the HP NetServer is operating in HP NetRAID mode, the HP NetRAID Adapter BIOS version is displayed, firmware initializes, and then DRAM = displays the capacity of the HP NetRAID DIMM.

  • Page 21: Warranty And Support, Hardware Accessories Limited Warranty, Hewlett-packard Hardware Accessories

    Service/Support Booklet for the warranty limitations, customer responsibilities, and other terms and conditions. Hardware Accessories Limited Warranty Hewlett-Packard Hardware Accessories An HP NetServer Hardware Accessory is an internal HP hardware product that is specifically designated for use with HP NetServers; is added on or integrated into an HP NetServer in order to provide higher performance, capacity, or increased capability;...

  • Page 22

    telephone assistance on replacement of the component; and pay shipping charges, duty, and taxes for any part that HP asks to be returned. HP warrants this HP NetServer Hardware Accessory against defects in material and workmanship, under normal use, for the period specified in the section titled HP NetServer Limited Warranty Coverage.

  • Page 23: Third-party Hardware Products, Hp Repair And Telephone Support

    Third-Party Hardware Products HP does not warrant third-party hardware products. Third-party hardware products may be warranted in accordance with the third-party warranty statement accompanying the product. On-site visits caused by third-party hardware products—whether internal to the HP NetServer system processor unit (such as non-HP DIMMs) or external to the system processor unit (such as LAN cabling)—are subject to standard per-incident travel and labor charges.

  • Page 25: Regulatory Information

    Regulatory Information For regulatory information pertaining to this HP accessory, please refer to the regulatory section of the installation guide for the HP NetServer in which this accessory is installed.
