8 Connecting the Monitor, Keyboard,
Mouse, and UPS

Introduction

This chapter explains how to connect a monitor, keyboard, mouse and
Uninterruptible Power Supply (UPS) to the communications ports at the rear of
the HP NetServer.

Procedure

Follow this procedure:
1. Connect the monitor, keyboard and mouse to the HP NetServer LXr Pro8.
Figure 8-1 shows which port to use for each device.
Connect Monitor
to Video Card
Rear of Satellite Chassis
Serial
Port B
I2C
Connector
Serial
Port A
Figure 8-1. Ports
Mouse
Port
Port 80
LEDs
Keyboard Parallel
Port Port
