HP D5970A - NetServer - LCII User Manual page 33

Chapter 3
1. Insert finger in each
fingerhold. Push
fingerholds toward
each other.
Figure 3-7. Unlatching HP NetServer's Top Cover
4. Maintain the pressure with your fingers and slide the cover away from
you. The cover slides about one-half inch before stopping. See Figure 3-7.
5. Lift the rear of the cover by the fingerholds. The cover swings open on its
hinges.
6. Swing open the cover until it is fully open, as shown in Figure 3-7. The
cover will rest in that position while you service the satellite.
Opening and Closing the
HP NetServer
2. Push cover forward
until it stops, then lift
cover by fingerholds.
25
