Power Supply

WARNINGS
Hazardous conditions, power supply: Hazardous voltage, current,
and energy levels are present inside the power supply. There are no
user-serviceable parts inside it; servicing should be done by technically
qualified personnel.

Removing a Power Supply

1. Disconnect the AC power cable from the system.
2. Remove the four screws (B in Figure 22) holding the power supply to the back of the chassis.
3. Using the flared, vertical edges as handles, slide the supply straight back from its bay (C in
Figure 22).
CAUTION
You might feel initial resistance in sliding the power supply from its bay.
Do not tilt or twist the supply; this can damage components. Resistance is
caused by the supply disengaging from its 40-pin connector. Use even,
steady force to remove the supply.
Figure 22. Removing a Power Supply
C
A
B
OM08020
83
