Diskette Drive

33
34
Table 34. Diskette Drive Connector Pinout
Pin Signal
1 GND
2 FD_DENSEL
3 GND
4 N/C
5 Key
6 FD_DRATE0
7 GND
8 FD_INDEX_L
9 GND
10 FD_MTR0_L
11 GND
12 FD_DR1_L
13 GND
14 FD_DR0_L
15 GND
16 FD_MTR1_L
17 FD_MSEN1
140
1
2
OM08030
Pin Signal
18 FD_DIR_L
19 GND
20 FD_STEP_L
21 GND
22 FD_WDATA_L
23 GND
24 FD_WGATE_L
25 GND
26 FD_TRK0_L
27 FD_MSEN0
28 FD_WPROT_L
29 GND
30 FD_RDATA_L
31 GND
32 FD_HDSEL_L
33 GND
34 FD_DSKCHG_L
