Toolbar
The tool bar buttons combine server control and management plug-in options available from the
Connect and Action Menus.
Connects to a selected server.
Disconnects from the currently connected server.
Powers the selected server on or off.
Resets the selected server.
Opens the SEL viewer.
Opens the SDR viewer.
Opens the FRU viewer.
Opens the phonebook.
Opens online help.

Status Bar

The status bar displays at the bottom of the current window. It contains the following status
information:
Server Name: The name of the connected server.
Line: The type of line connection (direct or modem).
Mode: Either redirect or EMP, depending on whether the EMP has control of the COM2 port.
Line Status: Gives status information on the server connection. For example, if a server is
connected, the status bar says "Connected." Otherwise, the line is blank.
EMP Console Main Menu
File
Exit: Exits the EMP console
Connect
Disconnect: Disconnects the server connection.
[Re]Connect: Raises the connect dialog.
(A list of the five most recent connections): Initiates connection to selected server.
Action
Power On/Off: Powers the server on or off with POST power-up options.
Reset: Resets the server with POST reset options.
SEL Viewer: Opens the SEL viewer.
SDR Viewer: Opens the SDR viewer.
FRU Viewer: Opens the FRU viewer.
Phonebook: Opens the phonebook dialog.
Help: Provides version information and help topics for the EMP console.
