Figure 13 shows the EMP console window in redirect state with the terminal window. The text
that appears on the server monitor displays in the redirect window.
Availability of the various EMP console features is determined by two things: the EMP access
mode selected during configuration in the System Management Submenu of the BIOS Server
Menu, and whether the server's COM2 port is configured for console redirect in BIOS. The three
EMP access modes are disabled, pre-boot, and always active.
Table 27.
EMP Console Access Modes (Server Configured for Console Redirect)
Mode
Server is powered off
Disabled
Redirect window appears, but is blank
Pre-boot
EMP commands available
Always Active
EMP commands available
*
You can modify the operation mode by selections in the POST reset and POST power-up dialogs. These are server
control dialogs available with the EMP Console.
Table 28.
EMP Console Access Modes (Server NOT configured for console redirect)
Mode
Server is powered off
Disabled
Redirect window appears,
but is blank
Pre-boot
EMP commands available
Always Active
EMP commands available
Figure 13. EMP Console in Redirect State
During POST
Redirect window appears,
but is blank
EMP commands available
EMP commands available
During POST
After OS boots
Redirect window
Redirect window
Redirect window*
Redirect window
Redirect window*
EMP commands available
After OS boots
Redirect window appears,
but is blank
Redirect window appears,
but is blank
EMP commands available
59
