Main Power Connector

1
11
Table 32. Main Power Connector Pinout
Pin Signal
1 +3.3 VDC
2 +3.3 VDC
3 +3.3 VDC
4 COM
5 COM
6 COM
7 COM
8 +12 VDC
9 +12 VDC
10 +12 VDC

Auxiliary Power

13 1
2
14
OM08033
Table 33. Auxiliary Power Connector Pinout
Pin Signal
1 RTN_RS
2 5V_RS
3 3.3V_RS
4 FAN_SPEED
5 I2CSCL
6 I2CSDA
7 GND
8 SYS_PGOOD
9 PS_ON
10 GND
11 -12VCC
12 Key
13 12V_RS
14 GND
10
20
OM08034
Wire Color
Orange
Orange
Orange
Black
Black
Black
Black
Yellow
Yellow
Yellow
Pin Signal
11 +3.3 VDC
12 +3.3 VDC
13 +3.3 VDC
14 COM
15 COM
16 COM
17 +5V Standby
18 +5 VDC
19 +5 VDC
20 +5 VDC
Wire Color
Orange
Orange
Orange
Black
Black
Black
Purple
Red
Red
Red
139
