Intel Server System SC5650HCBRP
®
Quick Start User's Guide
Thank you for buying the Intel ® Server System SC5650HCBRP.
The following information will help you assemble your Intel® Server System
SC5650HCBRP and install components.
These guides and other supporting documents are located on the web at
http://support.intel.com/support/motherboards/server/SC5520HC/
If you are not familiar with ESD (Electrostatic Discharge) procedures
used during system integration, please see the Intel® Server
System SC5650HCBRP Service Guide, available on the Intel® Server
Deployment Toolkit CD or at
http://support.intel.com/support/motherboards/server/SC5520HC/.
Please boot to the Intel® Server Deployment Toolkit CD first for BIOS and
firmware configuraion and updates.
Read all cautions and warnings first before starting your server
system integration.
5
Warning
Remove Hot Swap Drive Cage
Read all caution and safety
statements in this document
before performing any of the
instructions. Also see the Intel
®
Server Board and Server Chassis
Safety Information document at:
http://support.intel.com/support/
motherboards/server/sb/cs-010770
.htm for complete safety information.
Warning 1
Installation and service of
this product to be performed
only by qualified service
personnel to avoid risk of injury from
electrical shock or energy hazard.
1 Remove Hard Disk Carrier from Hot Swap Drive Cage
Caution
and disconnect all cables from the Expander Hot Swap
Drive Cage.
Observe normal ESD
[Electrostatic Discharge]
procedures during system
integration to avoid possible
7
damage to server board and/or
b
other components.
Install the Processor(s) ... continued
Tools Required
E. Install the Processor
Hex nut driver
(0.25 in or
6 mm)
CAUTION: The underside
of the processor has
components that may damage
#2 Phillips* Anti-static
the socket wires if installed
screwdriver wrist strap
improperly.
Intel is a registered trademark of Intel Corporation or its
subsidiaries in the United States and other countries.
*Other names and brands may be claimed as the
property of others. Copyright © 2009, Intel Corporation.
All rights reserved.
Components
Processor must align
correctly with the
socket opening
before installation.
E81444-002
DO NOT DROP processor
into the socket!
2
2
3
2
Push blue plastic release mechanism upward to
unlatch hard drive cage.
3 Once released, pull hard drive cage out of chassis.
F. Close Load Plate and Socket Lever
A A
Orient the processor with the socket
Close the
so that the orientation notches on
load plate
the processor align with the two A
all the
orientation posts on the socket.
way as
Install the processor as shown. shown.
Orientation Notches
B
With your finger, push down on the
load plate as shown.
C
Close the socket lever and ensure that
the load plate tab engages under the
A
socket lever when fully closed.
C
B
Orientation Posts
Minimum Hardware Requirements
To avoid integration difficulties and possible board damage,
your system must meet the following minimum requirements:
• Processor: Minimum of one Intel
5500 Series. Maximum 95-W processor.
• Heatsink(s): Minimum of one active heat sink.
• Memory Type: Minimum of one 1 GB, 240-pin,
RDIMM or UDIMM, DDR3-800, DDR3-1066, or DDR3-1333.
• SAS Controller: One SAS add-in card or SAS module card
• Hard Disk Drives: SATA/SAS
For a complete list of compatible processors, heatsinks,
and memory, see:
http://support.intel.com/support/motherboards/server/S5520HC/
3
Remove Front Bezel Assembly
1
1
1
Lift outward two bezel tabs on left side of bezel assembly to
detach bezel assembly from `the chassis.
2
Rotate left side of front bezel assembly outward slightly.
3 Disengage three bezel clips that attach the right side of the
bezel to the right side of the chassis and remove.
6
7a
Remove Fan Duct Install the Processor(s)
Cautions:
1. When opening a socket, DO NOT
TOUCH the gold socket wires.
1
Remove fan duct assembly as shown.
2. When unpacking a processor,
hold by the edges only to avoid
touching the gold contact wires.
1
8
Install DIMM Memory Modules
DDR3 DIMM Memory Identification: Memory Configurations and Population Order:
• Minimum of one 1 GB DDR3-800/1066/1333 RDIMM or UDIMM.
® • Install from first slot of each channel (A1, B1, C1, D1, E1, or F1).
The Intel Server System SC5650HCBRP
• Install Quad-Rank DIMM from first slot of each channel.
supports upto 12 DDR3-800/1066/1333
RDIMMs or UDIMMs. • Channel D, E, and F are not available when CPU 2 socket is empty.
• Mixing of RDIMMs and UDIMMs is not supported.
DIMM notch and
DIMM D2
socket bump must
DIMM D1
align as shown.
DIMM E2
DIMM E1
DIMM F2
DDR3
DIMM F1
2
1
Preparing Remove Side Cover
the Chassis
1
Remove two screws.
Xeon Processor
® ®
2
Observe normal ESD Push in latch.
(Electrostatic Discharge)
3
Slide side cover
procedures.
rearward and remove.
Place your
Intel Server
®
Chassis on a flat anti-static
surface to perform the following
integration procedures.
Observe ESD procedures before
reaching inside to make
server board connections
or install components.
4
Install Tool-less CD-ROM or DVD-ROM Drive
3
2
1
3
1
Remove EMI shield from 5.25-inch device
drive bay.
2
Make sure latch is in "unlock" position.
3
3
Insert CD-ROM or DVD-ROM drive into
device drive bay.
2
4
Line up holes in CD-ROM or DVD-ROM
drive with holes in chassis.
5
Move latch to "lock" position.
6
Connect power cables and data cables to rear
of the CD-ROM or DVD-ROM drive.
A. Open the Socket Lever B. Open the Load Plate
A
Push the rear tab with your
A
Push the lever handle down finger tip to bring the front
and away from the socket to end of the load plate
release it. up slightly.
B
Rotate the lever open all
the way.
A
B
B
Open the load plate as shown.
B
To Install DIMMs:
CAUTION: Avoid touching contacts
when handling or installing DIMMs.
A
Open both DIMM socket levers.
B
Note location of alignment notch.
C
Insert DIMM making sure the connector edge
of the DIMM aligns correctly with the slot.
D
Push down firmly on the DIMM until it
snaps into place and both levers close.
DIMM A2
E
IMPORTANT! Visually check that each
DIMM A1
latch is fully closed and correctly
DIMM B2
engaged with each DIMM edge slot.
DIMM B1
DIMM C2 C
CPU 1 Socket E
DIMM C1
D
A
CPU 2 Socket
1
2
3
1
4
6
5
3
An additional 4-pin IDE male-to-SATA 15 pin power cable
adapter may be needed if the CD-ROM or DVD-ROM does
not have a 4-pin power connector.
Data cables are included with the Intel ® Server System.
C. Remove Socket D. Remove the
Protective Cover Processor
A
Grasp the socket protective cover Protective Cover
by the two tabs and carefully lift
straight up as shown.
A
To avoid damage, DO
A
Take the processor
NOT DROP the cover
out of the box and
onto the socket wires
remove the protective
or components.
shipping cover.
Save the protective cover.
A
Go to Side 2
