Interrupts
The table below recommends the logical interrupt mapping of interrupt sources; it reflects a typical
configuration, but these interrupts can be changed by the user. Use the information to determine
how to program each interrupt. The actual interrupt map is defined using configuration registers in
the PIIX4E and the I/O controller. I/O Redirection Registers in the I/O APIC are provided for each
interrupt signal; the signals define hardware interrupt signal characteristics for APIC messages sent
to local APIC(s).
NOTE
To disable either IDE controller and reuse the interrupt: if you plan to
disable either IDE controller to reuse the interrupt for that controller, you
must physically unplug the IDE cable from the board connector (IDE0) if a
cable is present. Simply disabling the drive by configuring the SSU option
does not make the interrupt available.
Table 53.
Interrupts
Interrupt
I/O APIC level
INTR
INT0
NMI
N/A
IRQ1
INT1
Cascade
INT2
IRQ3
INT3
IRQ4
INT4
IRQ5
INT5
IRQ6
INT6
IRQ7
INT7
IRQ8_L
INT8
IRQ9
INT9
IRQ10
INT10
IRQ11
INT11
IRQ12
INT12
INT13
IRQ14
INT14
IRQ15
INT15
SMI_L
Description
Processor interrupt
NMI from PIC to processor
Keyboard interrupt
Interrupt signal from second 8259 in PIIX4E
Serial port A or B interrupt from SIO device (user can configure)
Serial port A or B interrupt from SIO device (user can configure)
Parallel port II
Diskette port
Parallel port
RTC interrupt
Signal control interrupt (SCI) used by ACPI-compliant OS
Mouse interrupt
Compatibility IDE interrupt from primary channel IDE devices 0 and 1
System management interrupt—general purpose indicator sourced
by the PIIX4E and BMC through the PID to the processors
157
