Table 26. FRU Manager Menus
Menu Options
File Open FRU: Opens FRU data from a previously saved file
Save FRU: Saves FRU data to a file in binary raw or verbose text format
Exit: Quits the FRU Manager
View FRU Info: Displays FRU information of the selected device
All FRU Areas: Displays FRU areas of all devices
By Device Type: Displays FRU areas sorted by device type
Settings Display HEX: Displays FRU areas in Hex format
Display Verbose: Displays FRU areas in verbose format
Output Text: Saves FRU data in verbose format
Output Binary: Saves FRU data in binary format
Help About: Displays FRU Manager version information

Exiting the SSU

Exiting the SSU causes all windows to close.
1. Exit the SSU by opening the menu bar item File in the SSU Main window.
2. Click <Exit>
or
Highlight Exit, and press <Enter>.

Emergency Management Port (EMP) Console

The EMP console provides an interface, called the console manager, to the EMP. This interface
allows remote server management via a modem or direct connection.
The following server control operations are available with the console manager:
Connecting to remote servers
Powering the server on or off
Resetting the server
Switching the server console between EMP active and BIOS re-direct modes
The console manager uses three management plug-ins to monitor the server: the SEL, SDR, and
FRU viewers.
The console manager also has a support plug-in phonebook, which you can use to create and
maintain a list of servers and their phone numbers. You can launch the Connect dialog directly
from the Phonebook dialog to connect to a selected server.
57
