Chapter 1 Introducing the Sensor
Attach the wrist strap to your wrist and to the terminal on the work surface. If you are using a disposable
Step 3
wrist strap, connect the wrist strap directly to an unpainted metal surface of the chassis.
Step 4 Connect the work surface to the chassis using a grounding cable and alligator clip.
Always follow ESD-prevention procedures when removing, replacing, or repairing components.
Caution
Note

Cable Pinouts

This section describes pinout information for 10/100/1000BaseT, console, and RJ 45 to DB 9 ports, and the
MGMT 10/100 Ethernet port. It contains the following topics:
•
•
•
OL-18504-01
If you are upgrading a component, do not remove the component from the ESD packaging until
you are ready to install it.
10/100BaseT and 10/100/1000BaseT Connectors, page 1-34
Console Port (RJ-45), page 1-35
RJ-45 to DB-9 or DB-25, page 1-36
Cisco Intrusion Prevention System Appliance and Module Installation Guide for IPS 7.0
100 Mbps Link
FDX FAILOVER
100 Mbps Link
FDX
10/100 ETHERN ET 0/0
10/100 ETHERN ET 0/0
CONSOL E
Cable Pinouts
Copper foil
1-33
