Chapter 4 Installing the IPS 4270-20

Accessories

The IPS 4270-20 accessories kit contains the following:
•
•
•
•
•

Installing the Rail System Kit

You can install the IPS 4270-20 in a 4-post rack. This section describes how to install the IPS 4270-20
in a rack, and contains the following sections:
•
•
•
•
•
•
•
Understanding the Rail System Kit
This rail system supports a variety of products that can be installed in round-, square, or threaded-hole
racks. The following illustration shows the three rack hole-types. Use
type and then follow the installation steps accordingly.
Figure 4-11
Round-hole racks
No tools required
OL-18504-01
DB-9 connector
DB-9/RJ-45 console cable
Two Ethernet RJ-45 cables
Regulatory Compliance and Safety Information for the Cisco Intrusion Detection and Prevention
System 4200 Series Appliance Sensor
Documentation Roadmap for Cisco Intrusion Prevention System
Understanding the Rail System Kit, page 4-15
Rail System Kit Contents, page 4-16
Space and Airflow Requirements, page 4-16
Installing the IPS 4270-20 in the Rack, page 4-17
Extending the IPS 4270-20 from the Rack, page 4-25
Installing the Cable Management Arm, page 4-28
Converting the Cable Management Arm, page 4-31
Round-, Square-, and Threaded-Hole Racks
Square-hole racks
No tools required
Cisco Intrusion Prevention System Appliance and Module Installation Guide for IPS 7.0
Figure 4-11
Threaded-hole racks
Tools required:
standard screwdriver,
Phillips screwdriver,
or T-25 Torx driver
Accessories
to identify your rack
4-15
