Chapter 4 Installing the IPS 4270-20
Table 4-3
Table 4-3
Fail Indicator 1
Amber
Off
Flashing
On
Off
Off

Diagnostic Panel

The front panel health indicators only indicate the current hardware status. The Diagnostic Panel
indicators identify components experiencing an error, event, or failure. All indicators are off unless one
of the component fails.
When you remove the chassis cover to view the Diagnostic Panel, leave the IPS 4270-20 powered on.
Note
Powering off the IPS 4270-20 clears the Diagnostic Panel indicators.
Figure 4-9
Figure 4-9
POWER
FAULT
OL-18504-01
describes the power supply indicators.
Power Supply Indicators
Power Indicator 2
Green
Off
Off
Off
Flashing
On
shows the Diagnostic Panel.
Diagnostic Panel
NMI
FAN4
MEMORY
FAN3
PROC2
!
PROC4
!
Cisco Intrusion Prevention System Appliance and Module Installation Guide for IPS 7.0
Description
No AC power to any power supply
Power supply failure (over current)
No AC power to this power supply
AC power present
•
Standby mode
•
Normal
FAN6
MEMORY
FAN5
PROC1
!
FAN2
FAN1
PROC3
!
Diagnostic Panel
INTERLOCK
ERROR
CPU BD
4-11
