Interfaces
Configure a bridge
Required configuration items
A name for the bridge.
n
Bridges are enabled by default.
Devices to be included in the bridge.
n
Additional configuration items
Enable Spanning Tree Protocol (STP).
n
To create a bridge:
Web
1. Log into Digi Remote Manager, or log into the local Web UI as a user with full Admin access
rights.
2. Access the device configuration:
Remote Manager:
a. Locate your device as described in
device.
b. Click the Device ID.
c. Click Settings.
d. Click to expand Config.
Local Web UI:
a. On the menu, click System. Under Configuration, click Device Configuration.
The Configuration window is displayed.
3. Click Network > Bridges.
4. For Add Bridge, type a name for the bridge and click .
5. Bridges are enabled by default. To disable, toggle off Enable.
6. For Bridge type, select Standard.
See
Create a VLAN using switchport mode
7. (Optional) Enable Spanning Tree Protocol (STP).
STP is used when using multiple LANs on the same device, to prevent bridge loops and other
routing conflicts.
a. Click STP.
b. Click Enable.
AnywhereUSB Plus User Guide
Use Digi Remote Manager to view and manage your
for information about switchport bridging.
Bridging
306
