NTRODUCTION
Thanks for purchasing the MIL-H3130 Dual Speed Hub.
It can easily combine 10 Mbps Ethernet segments and
100 Mbps Fast Ethernet segments. The hub can make
your network environment more efficient, give you
unmatchable flexibility, high performance, and robust
functions.
The MIL-H3130 Dual Speed Hub provides 8 auto-sensing
RJ-45 twisted pair ports on the front panel. With the auto-
sensing feature, the ports can detect transmission rates in
10 Mbps or 100 Mbps automatically. The concise LED
indicators help you to recognize the link status and
simplify troubleshooting. You can easily connect the hub
with other network devices. There is an extra RJ-45 port
provided for cascading to another hub or switch using
straight-through Category 5 twisted pair cable.
Installation Guide
MIL-H3130 8-port 10/100
Dual Speed Hub
The MIL-H3130 Dual Speed Hub has the following
features:
!
Complies with IEEE802.3, IEEE802.3U standards
!
8 10/100 Mbps auto-sensing ports
!
One up-link port provided for cascading
!
Visual diagnostic LED's
!
Palm size
!
External power adapter
MH18RDV00ADH
