Services
(config)> service snmp port port
(config)>
8. (Optional) Configure Multicast DNS (mDNS)
mDNS is a protocol that resolves host names in small networks that do not have a DNS
server. For the SNMP agent, mDNS is disabled by default. To enable:
(config)> service snmp mdns enable true
(config>
9. (Optional) Set the authentication type. Allowed values are MD5 or SHA. The default is MD5.
(config)> service snmp auth_type SHA
(config)>
10. (Optional) Set the privacy passphrase. If not set, the password, entered above, is used.
(config)> service snmp privacy pwd
(config)>
11. (Optional) Set the privacy protocol, either DES or AES. The default is DES.
(config)> service snmp privacy_protocol AES
(config)>
12. (Optional) Add Dynamic SNMP Properties to expose specific details about your device for
SNMP monitoring that are not included in the standard MIB.
(config) service snmp runt> add end value
(config)>
Where value can be any element in the runtime table you want to expose to SNMP monitoring
(for example, " system.cpu_temp" or " system.name" ).
13. (Optional) Enable read-only access to to SNMP version 2c.
(config)> service snmp enable 2c true
(config)>
The community name is set to public by default. You can change it if desired.
(config)> service snmp community_name <name>
(config)>
Where name is the new community name.
14. Save the configuration and apply the change.
(config)> save
Configuration saved.
>
