Routing
10. Click  to add a virtual IP address.
11. For Virtual IP, type 192.168.3.3.
Task 2: Configure VRRP+ on device one
1. Click to expand VRRP+.
2. Click Enable.
3. Click to expand Monitor interfaces.
4. Click  to add an interface for monitoring.
5. Select Interface: Modem.
6. For Priority modifier, type 30.
Task 3: Configure the IP addressfor the VRRP interface, ETH2, on device one
1. Click Network > Interfaces > ETH2 > IPv4
2. For Address, type 192.168.3.1/24.
Task 4: Configure the DHCP server for ETH2 on device one
1. Click to expand Network > Interfaces > ETH2 > IPv4 > DHCP Server
2. For Lease range start, leave at the default of 100.
3. For Lease range end, type 199.
4. Click to expand Advanced settings.
5. For Gateway, select Custom.
6. For Custom gateway, enter 192.168.3.3.
