Virtual Private Networks (VPN)
Show NEMO status

Web
Log into the AnywhereUSB Plus WebUI as a user with full Admin access rights.
1. On the menu, select Status > NEMO.
The NEMO page appears.
2. To view configuration details about an NEMO tunnel, click the  (configuration) icon in the
upper right of the tunnel's status pane.

Command line
1. Select the device in Remote Manager and click Actions > Open Console, or log into the
AnywhereUSB Plus local command line as a user with full Admin access rights.
Depending on your device configuration, you may be presented with an Access selection
menu. Type admin to access the Admin CLI.
2. To display details about all configured NEMO tunnels, type the following at the prompt:
> show nemo
NEMO Enable
---- ------
demo false
test true
>
3. To display details about a specific tunnel:
> show nemo name test
test NEMO Status
----------------
Enabled
Status
Home Agent
Care of Address
Interface
GRE Tunnel
Metric
MTU
Lifetime (Actual)
Local Network
-------------
lan1
LAN2
AnywhereUSB Plus User Guide
Status Address Agent
------ ------- -------
up 1.2.3.4 4.3.2.1
: true
: up
: 4.3.2.1
: 10.10.10.1
: modem
: 10.10.10.1 === 4.3.2.1
: 255
: 1476
: 600
Subnet Status
-------------- ----------
192.168.2.1/24 Advertized
192.168.3.1/24 Advertized
CoAddress
----------
10.10.10.1
NEMO
