Status/Job Cancel > Device Information

Device Information

Configure the devices/lines installed or connected to this machine or check their status.
1
Display the screen.
1 Select the [Home] key.
2 Select [...] > [Device Information] Confirmation on the machine status or window for operation will
appear.
2
Check the information.
The items you can check are described below.
[Identification/Wired Network]
You can check ID information such as the model name, serial number, host name and location, and
the IP address of the wired network.
[Wi-Fi Direct/Wi-Fi]
You can check the status of Wi-Fi connection, such as the device name, network name and IP address.
NOTE
Displayed when the optional Wireless Network Interface Kit is installed.
[Supplies/Paper]
You can check the availability of toner and paper.
➡
Checking the Remaining Amount of Toner and Paper (page 394)
[Fax]
You can check the local fax number, local fax name, local fax ID and other fax information. For details,
refer to the following:
➡ FAX Operation Guide
NOTE
This item is displayed for fax-compatible machines.
[USB/Bluetooth]
You can check the connection status of USB drive and Bluetooth keyboard.
• Select "USB Drive" for [Format] if you wish to format external media.
IMPORTANT
When [Format] is selected, all data in the USB drive is erased.
• Select "USB Drive" for [Remove] to safely remove the external media.
• Select "Bluetooth" for [Connect] to establish the Bluetooth keyboard connection.
392
