Kyocera ECOSYS MA2600cwx Operation Manual page 638

Troubleshooting > Troubleshooting
NOTE
• If you selected [Search Folder from Network], you can search all PCs on the network for a
destination.
• If you selected [Search Folder by Host Name], you can search for a destination from among PCs that
are connected to the network by entering "Domain/Workgroup Name"/"Host Name".
• A maximum of 500 addresses can be displayed. Select the host name (PC name) that you want to
specify in the screen that appears, and select [OK]. The login user name and login password entry
screen appears.
• After you enter the login user name and login password of the destination PC, the shared folders
appear. Select the folder that you want to specify and select [OK]. The address of the selected shared
folder is set.
Are the folder sharing settings configured correctly?
Check the sharing settings and access permissions in the folder properties.
1
Right-click the shared folder and click [Properties]
2
Select a user and make sure the user you entered in the group name or user name
field is displayed
3
Make sure that [Allow] is checked off for "Modify" and "Read & Execute"
4
Click the [Close] button.
➡
Creating a Shared Folder, Making a Note of a Shared Folder (page 161)
Is the selected interface selected as the Primary Network?
Make sure the selected interface is selected as the Primary Network.
1
[System Menu/Counter] key > [NetworkSettings] > "Others" [Primary Network
(Client)]
NOTE
[Primary Network (Client)] is displayed when the optional Network Interface Kit (IB-50) or Wireless
Network Interface Kit (IB-37/IB-38/IB-51) is installed.
2
Specify the host name or IP address of the interface selected as the Primary
Network, or reconfigure it to the interface you want to use.
For example, if you selected the [Optional Network]optional network as the Primary Network, specify the
host name or IP address of IB-50 or IB-51.
[Security] tab.
629
