Obtain Nw User Property - Kyocera ECOSYS MA2600cwx Operation Manual

User Authentication and Accounting (User Login, Job Accounting) > Setting User Login Administration

Obtain NW User Property

Set the required information to obtain the network user property from the LDAP server. The user name and
E-mail address obtained with this setting is shown in the user information, the status confirmation screen, and
the header of E-mail.
NOTE
To obtain the network user property from the LDAP server, [Network Authentication] must be selected for the
user authentication method in "User Login Setting". In addition, set [LDAP] to On in "Protocol Settings".
➡
Enable User Login Administration (page 522)
➡
Protocol Settings (page 475)
1
Display the screen.
1 [System Menu/Counter] key > [Job Accounting/Authentication]
NOTE
If the user authentication screen appears, log in with a user who has the privilege to configure this
setting. If you do not know your login user name or password, please contact your administrator.
2 Select [Obtain NW User Property] from "User Login Setting".
2
Configure the settings.
1 Enable "Obtain NW User Property" to configure the settings.
LDAP Server Information
Server Name
Enter the LDAP server name or the IP address (up to 64 characters). If a server name is not
entered, user information will be acquired from the server set for Network Authentication.
Port
Port number for LDAP server. The default port number is 389.
Acquisition of User Information
*2
Name 1
Enter the LDAP Attribute to obtain the user name to be displayed from the LDAP server (up to
32 characters).
*3
Name 2
Enter the LDAP Attribute to obtain the user name to be displayed from the LDAP server (up to
32 characters).
Email Address
Enter the LDAP Attribute to obtain the E-mail address from the LDAP server (up to 256
characters).
*1
*4
545
