Graphics Board

The following specifications apply to the graphics boards available with the
system.

AccelGRAPHICS AccelSTAR II 2D/3D PCI Board Specifications

The specifications for the AccelGRAPHICS AccelSTAR II (3D Labs
Permedia 2A) 2D/3D PCI board are included in the following table.
Feature
Chipset
Video memory
Resolutions
Refresh rates
Color depth:

AccelGRAPHICS AccelECLIPSE II PCI Board Specifications

The specifications for the AccelGRAPHICS AccelECLIPSE II PCI board are
included in the following table.
Feature
Chipset
Video memory
Resolutions
Refresh rates
Color depth
10-12 Specifications

AccelSTARII Specifications

Specification
Permedia II
8MB
640 x 480, 800 x 600, 1024 x 768,
1152 x 870, 1280 x 1024, 1600 x 1200
60, 72, 75, 85, 100 (not all refresh rates are
available at all resolutions)
256, 32K, 65K,16.7M/true color (varies by
resolution)
™
AccelECLIPSE II Specifications
Specification
3D Pro
32 MB
640 x 480, 800 x 600, 1024 x 768,
1280 x 1024
60, 72, 75, 85 (not all refresh rates are available at
all resolutions)
16.7M (true color)
