Primary Ide Master And Slave Submenu - NEC PowerMate Professional 9000E Series Service Manual

Feature
Type
Multi-Sector
Transfer
LBA Mode
Control
32 Bit I/O
Transfer Mode
Ultra DMA
Mode
2-10 System Configuration

Primary IDE Master and Slave Submenu

Choices Description
Auto Auto allows the system to attempt auto-detection
None of the drive type. None informs the system to
CD-ROM ignore this drive. CD ROM allows the manual
User entry of fields described below. User allows the
manual entry of all fields described below.
Disabled Determines the number of sectors per block for
2, 4, 8, or multi-sector transfers.
16 sectors
This field is informational only for Type Auto.
Disabled Enabling LBA causes logical block addressing to
Enabled be used in place of cylinders, heads, and sectors.
This field is informational only for Type Auto.
Disabled Enabling allows 32 bit IDE data transfers.
Enabled
Standard Selects the method for moving data to and from
Fast PIO 1 the drive.
Fast PIO 2
Fast PIO 3 This field is informational only for Type Auto.
Fast PIO 4
Disabled Selects the Ultra DMA Mode for moving data to
and from the drive. Autotype the drive to select
Enabled
the optimum transfer mode.
This field is informational only for Type Auto.
