3C905-TX Network Board
The specifications for the 3Com 3C905-TX network board are included in the
following table.
Feature
Network Board
Features
Dimensions
Operating Ranges
Power
3COM 3C905-TX Network Board Specifications
Specification
3COM 3C905-TX
10/100Base Ethernet card
10Base-T connector
32-bit bus master PCI design
Single driver configuration
Automated 10/100 NWay speed auto-negotiation
AutoLink configuration software for NetWare
drivers
Support for Plug and Play
Custom ASIC combining 10/100 bus interface and
IEEE 802.3 and 802.3u compliant
PCI 2.1 compliant
L x W, 3.375 in x 4.75 in.
Temperature 32 to 158 F (0 - 70 )
Humidity 10-90% (non-condensing)
Altitude to 9800 ft.
Power Requirements: +5V +/- 5% at 650 mA max
in Fast EtherLink XL PCI
8 KB RAM on one chip
Specifications 10-13
