3-8 Option Installation

Expansion Board Removal

1. Remove the system unit cover as previously described.
Label and remove any cables connected to the board.
2.
Remove the screw that secures the board to the support bracket (see Figure
3.
Section 3-6
4. Pull the board out of the connector. Gently rock the board from side-to-side to
release it from its connector.
5. Replace the system unit cover.
NOTE: To remove a board from an inside slot
in the desktop, see Inside Slot Expansion Board
Removal.
Figure Section 3-6 Removing the Screw
