Technical Information
1-17
HARD DISK DRIVE
Up to four IDE hard drives are supported in the system. The system board has two
IDE/PCI interface connectors (primary and secondary) for connecting various storage
devices such as hard disk drives. Each connector supports up to two IDE devices.
Hard disk systems ship with one internal 3 1/2-inch hard disk (1-inch high, thin-height)
installed behind the front panel, at the bottom of the chassis. The three-connector drive
cable plugs into the primary (fast) connector on the system board. An optional second hard
drive can be connected to the cable.
KEYBOARD
A Windows 95 104 key keyboard is standard equipment for the system. The keyboard
provides a numeric keypad, separate cursor control keys, and 12 function keys, capable of
up to 48 functions. Status lamps on the keyboard indicate: Num (Numeric) Lock, Caps
(Capital) Lock, and Scroll Lock key status. The keyboard's six-pin connector plugs into the
rear of the system. The keyboard connector pin assignments are given in Appendix A.
