3-34
Option Installation
8.
Replace the system unit cover.
9.
Run the Setup program to set the new configuration.
Replacing the Front Panel
Replace the front panel only after it has been removed in a 5 1/4-inch device installation.
Route the LED and IR cables on the front panel through the chassis to the system
1.
board, and connect the cables to the board.
2.
Align the six front panel metal clips with the holes in the front of the system unit
(see Figure Section 3-27).
3.
Evenly press the front panel into position until the clips lock the panel in place.
Go to Step 8, Installing the 5 1/4-Inch Device, to complete the installation.
4.
NOTE: If a 1.2-MB diskette drive was
installed, remove the protective cardboard insert
from the drive.
Figure Section 3-27 Aligning the Front Panel
