Repair
Front Panel Assembly Removal
Remove the front panel from the system unit as follows.
1.
Remove the system unit cover as previously described (see "System Unit Cover
Removal" in this section).
The front panel is secured with six metal clips (see Figure Section 5-6). Remove
2.
the front panel by evenly and carefully pulling the panel off the chassis.
Use care to prevent pulling on the LED and IR cables attached to the panel.
3.
Label and disconnect the LED and IR cables from the system board.
4.
Pull the left side out enough to clear the power, reset, and suspend buttons. When
the buttons have been cleared, slide the right side of the front panel out from the
system unit.
Figure Section 5-5 Removing a SIMM
NOTE: For information on installing SIMM
sticks, see Section 3, "Options".
Figure Section 5-6 Removing the Front Panel
