5-4 Repair
5. Lift the cover up and away from the system unit.

Expansion Board Removal

Remove the any installed expansion board(s) per the following steps.
Remove the system unit cover as previously described (see "System Unit Cover
1.
Removal" in this section).
Label and remove any cables connected to the board.
2.
Remove the screw that secures the board to the support bracket (see Figure
3.
Section 5-3
Pull the board out of the connector. Gently rock the board from side-to-side to
4.
release it from its connector.
Replace the system unit cover.
5.

SIMM Removal

Remove a SIMM from the system board as follows.
Figure Section 5-3 Removing the Screw
CAUTION: Reduce static discharge by touching
the system's metal chassis.
