HANGCHA CPCD15 Operation And Maintenance Manual page 46

3. Body and other parts
Load-backrest
The load-backrest ensures the stable loading of
cargo. The forklift truck must not be operated
without a load-backrest.
Driver's seat
4
1
1. Driver's seat weight adjustment handle
2. Forward and backward adjustment handle
for the driver's seat
3. Backrest angle adjustment handle
4. Handrail adjustment knob
· Driver's seat weight adjustment
The weight adjustment lever can be lifted and
put in the corresponding horizontal weight
position for the user.
· Forward and backward adjustment of the
driver's seat
Pull the adjustment handle inward by hand,
then push the whole seat forward and
backward to reach the desired position, the
handle is automatically locked when lowered.
· Backrest angle adjustment
While sitting on the driver's seat, lean back on
the backrest, pull
adjustment lever upward with your left hand,
lean forward or backward, and release the
lever until the backrest angle reaches the
desired position.
·Handrail adjusting
The handrail tilt angle can be adjusted by
rotating the adjustment knob. When rotating
the knob outward, the front end of the
handrail will lift. When rotating the knob
inward, the front end of the handrail will lower.
Warning
The ignition key switch must be turned

off before adjusting the driver's seat.
The seat position can be adjusted only

42
3
2
the backrest
when the forklift truck has stopped.
For safety reasons, do not adjust the

driver's seat when driving.
For front and rear adjustment and

backrest angle adjustment, the handle
should be pulled into place to ensure
that
disengaged before adjustment.
After adjustment, the levers should

return to the locked position. Ensure
that all the components are locked
securely before using the forklift truck.
Safety belt
· Fasten the safety belt
An additional action is required before pulling
out the safety belt which may require some
familiarization.
One type of seat: You need to press the white
round button (with the text "press to release")
with one hand, and then the seat belt can be
pulled out with the other hand. Then, the belt
can be inserted into the socket on the other
side of the driver's seat.
You may also encounter another kind of
driver's seat: The driver's seat with a rotating
safety belt box. When the safety belt box is
rotated forward, the safety belt cannot be
pulled out; when the box is rotated backward,
the safety belt can be pulled out and inserted
into the socket on the other side of the driver's
seat; the safety belt box has to be rotated
forward again to return to the normal working
position.
Your back and waist should be as close to the
driver's seat as possible when fastening the
angle
safety belt. Do not fasten the safety belt at the
abdomen.
Do not tilt the backrest too much; otherwise,
the safety belt will not be extended correctly.
Do not knot or twist the belt.
Keep the safety belt fastened tightly during
the structure is completely
