10
12
When the pedal is pressed, the oil pressure of
the hydraulic clutch will drop. When the pedal
is pressed harder, the forklift truck will be
braked. The pedal can be used when the
forklift truck slows down to approach cargo or
conducts loading and unloading operations.
Caution
Do not use

excessively. If the pedal is used as a
footrest or used for a long time, it may
cause overheating of the automatic
transmission oil or clutch slip.
Emergency power-off switch [14]
Press down the emergency power-off switch to
disconnect the electric appliances from the
battery.
If the forklift truck needs to be restarted, the
emergency power-off
toggled.
Turn off the emergency power-off switch 30s
after shutdown.
Hand brake lever [15]
Loosen
Pull the lever back to engage and push the
lever forward to release. Engage the lever
before the leaving the forklift truck.
40
the inching pedal
switch should
Button
Block
Caution
In the event of brake system failure or

an emergency, the lever can be engaged
for emergency braking. Do not use the
hand brake to slow down during normal
use.
Adjusting lever for steering wheel tilt angle [16]
The position of the steering wheel can be
adjusted. To perform adjustment, pull the
adjusting lever installed on the left side of the
steering hub column, move the steering wheel
to the desired position, and push down the
adjusting lever to lock.
Caution
Adjust the steering wheel tilt angle only

after the forklift truck has stopped and
the hand brake is engaged.
be
Forcibly move the steering wheel up

and down to ensure that it has been
locked after adjusting.
Direction lever [17]
The direction lever is installed on the left side
of the steering hub column. This series of
forklift trucks adopt electrical steering and the
functions realized by moving the lever forward
and backward are as follows:
1、
F2
F1
N
R
16
12
Forward Gear II
Forward Gear I
Neutral
Reverse
