ST9917, ST9920, ST9921

User's Manual

PN 109441

11401A Granite Street | Charlotte, NC | 800.922.8501 |

Sourcetech.com

Need help?

Do you have a question about the ST9917 and is the answer not in the manual?

Questions and answers

Summary of Contents for Source Technologies ST9917

Page 1 ST9917, ST9920, ST9921 User's Manual PN 109441 11401A Granite Street | Charlotte, NC | 800.922.8501 | Sourcetech.com...
Page 2 Mono Laser Printers User's Guide July 2023 Machine type: 4602 Models: 480, 680, 685, and their equivalent models...
Page 3 Contents Contents Safety information..................5 Conventions................................5 Product statements............................. 5 Learn about the printer................8 Finding the printer serial number........................8 Printer conﬁgurations............................8 Using the control panel............................9 Understanding the status of the indicator light..................10 Selecting paper..............................11 Set up, install, and conﬁgure..............17 Selecting a location for the printer.........................17 Attaching cables..............................
Page 4 Contents Printing a font sample list..........................54 Placing separator sheets between copies....................54 Canceling a print job............................54 Adjusting toner darkness..........................54 Use printer menus..................55 Menu map................................55 Device.................................. 56 Print..................................67 Paper..................................75 USB Drive................................77 Network/Ports..............................78 Security................................. 91 Reports................................. 98 Troubleshooting..............................99 Forms Merge..............................
Page 5 Contents Network connection problems........................156 Hardware options problems......................... 159 Issues with supplies............................160 Paper feed problems............................161 Contacting customer support........................163 Notices......................164 Index......................175...
Page 6 Safety information Safety information Conventions Note: A note identiﬁes information that could help you. Warning: A warning identiﬁes something that could damage the product hardware or software. CAUTION: A caution indicates a potentially hazardous situation that could injure you. Different types of caution statements include: CAUTION—POTENTIAL INJURY: Indicates a risk of injury.
Page 7 Safety information CAUTION—SHOCK HAZARD: To avoid the risk of electrical shock, make sure that all external connections (such as Ethernet and telephone system connections) are properly installed in their marked plug-in ports. CAUTION—SHOCK HAZARD: To avoid the risk of electrical shock, if you are accessing the controller board or installing optional hardware or memory devices sometime after setting up the printer, then turn the printer off, and unplug the power cord from the electrical outlet before continuing.
Page 8 Safety information CAUTION—POTENTIAL INJURY: This product uses a laser. Use of controls or adjustments or performance of procedures other than those speciﬁed in the User’s Guide may result in hazardous radiation exposure. CAUTION—POTENTIAL INJURY: The lithium battery in this product is not intended to be replaced. There is a danger of explosion if a lithium battery is incorrectly replaced.
Page 9 Learn about the printer Learn about the printer Finding the printer serial number Open door A. Locate the serial number. Printer conﬁgurations CAUTION—TIPPING HAZARD: Installing one or more options on your printer or MFP may require a caster base, furniture, or other feature to prevent instability causing possible injury. For more information on supported conﬁgurations, contact the place where you purchased the printer.
Page 10 Learn about the printer You can conﬁgure your printer by adding up to three optional 250‑ or 550‑sheet trays. For more information, “Installing optional trays” on page Standard bin Control panel Multipurpose feeder Standard 250- or 550-sheet tray Optional 250- or 550-sheet tray Using the control panel Panel with 2.8-inch touch‑screen display...
Page 11 Learn about the printer Control panel part Function Power button • Turn on or turn off the printer. Note: To turn off the printer, press and hold the power button for ﬁve seconds. • Set the printer to Sleep mode. •...
Page 12 Learn about the printer Indicator light Printer status Blinking amber The printer is in Deep Sleep or Hibernate mode. Selecting paper Paper guidelines Use the appropriate paper to prevent jams and help ensure trouble‑free printing. • Always use new, undamaged paper. •...
Page 13 Learn about the printer Grain direction Grain refers to the alignment of the paper ﬁbers in a sheet of paper. Grain is either grain long which runs the length of the paper, or grain short which runs the width of the paper. For recommended grain direction, see the “Supported paper weights”...
Page 14 Learn about the printer Selecting preprinted forms and letterhead • Use grain long paper. • Use only forms and letterhead printed using an offset lithographic or engraved printing process. • Avoid paper with rough or heavily textured surfaces. • Use inks that are not affected by the resin in toner. Inks that are oxidation‑set or oil‑based generally meet these requirements;...
Page 15 Learn about the printer Paper size Standard 250‑ or Optional 250‑ or Multipurpose feeder Two‑sided 550‑sheet tray 550‑sheet tray printing Statement 139.7 x 215.9 mm (5.5 x 8.5 in.) Executive 184.2 x 266.7 mm (7.25 x 10.5 in.) Letter 215.9 x 279.4 mm (8.5 x 11 in.) Legal 215.9 x 355.6 mm...
Page 16 Learn about the printer Paper size Standard 250‑ or Optional 250‑ or Multipurpose feeder Two‑sided 550‑sheet tray 550‑sheet tray printing 10 Envelope 104.8 x 241.3 mm (4.12 x 9.5 in.) DL Envelope 110 x 220 mm (4.33 x 8.66 in.) C5 Envelope 162 x 229 mm (6.38 x 9.01 in.)
Page 17 Learn about the printer Paper type Standard 250‑ or Optional 250‑ or Multipurpose feeder Two‑sided printing 550‑sheet tray 550‑sheet tray Light Paper Heavy Paper Rough/Cotton Envelope Rough envelope * One‑sided paper labels are supported for occasional use of less than 20 pages per month. Vinyl, pharmacy, or two‑sided labels are not supported.
Page 18 Set up, install, and conﬁgure Set up, install, and conﬁgure Selecting a location for the printer • Leave enough room to open trays, covers, and doors and to install hardware options. • Set up the printer near an electrical outlet. CAUTION—POTENTIAL INJURY: To avoid the risk of ﬁre or electrical shock, connect the power cord to an appropriately rated and properly grounded electrical outlet that is near the product and easily accessible.
Page 19 Set up, install, and conﬁgure Front 305 mm (12 in.) Note: The minimum space needed in front of the printer is 76 mm (3 in.). Left side 110 mm (4.33 in.) Attaching cables CAUTION—SHOCK HAZARD: To avoid the risk of electrical shock, do not set up this product or make any electrical or cabling connections, such as the power cord, fax feature, or telephone, during a lightning storm.
Page 20 Set up, install, and conﬁgure Icon Function Stop or Cancel button Stop the current printer task. Status/Supplies • Show a warning or error message whenever the printer requires intervention to continue processing. • View more information on the printer warning or message and how to clear it. Note: You can also access this setting by touching the top section of the home screen.
Page 21 Set up, install, and conﬁgure • To customize an app name, select the app name, click Edit, and then assign a name. • To restore the name of an app, select the app name, click Edit, and then select Restore app label. •...
Page 22 Set up, install, and conﬁgure Setting up Device Quotas Notes: • This application is supported only in some printer models. • For information on how to conﬁgure the application settings, see the Device Quotas Administrator’s Guide. Open a web browser, and then type the printer IP address in the address ﬁeld. Notes: •...
Page 23 Set up, install, and conﬁgure Note: The application supports the following ﬁle types: PDF, JPEG, and TIFF. Other ﬁle types such as DOCX and XLSX are supported in some printer models. Click Save. Creating folders Open a web browser, and then type the printer IP address in the address ﬁeld. Notes: •...
Page 24 Set up, install, and conﬁgure Setting up and using the accessibility features Activating Voice Guidance From the home screen In one motion and using one ﬁnger, slowly swipe left then up on the display until you hear a voice message. Note: For printer models without built-in speakers, use headphones to hear the message.
Page 25 Set up, install, and conﬁgure Gesture Function Swipe left then up using one ﬁnger Launch Accessibility mode. Use the same gesture to exit Accessibility mode. Note: This gesture is also applicable when the printer is in normal mode. Double‑tap using one ﬁnger Select an option or item on the screen.
Page 26 Set up, install, and conﬁgure For more information on navigating a magniﬁed screen, see “Navigating the screen using gestures” on page Adjusting the Voice Guidance speech rate From the home screen, touch Settings > Device > Accessibility > Speech Rate. Select the speech rate.
Page 27 Set up, install, and conﬁgure Conﬁguring Universal paper settings From the home screen, touch Settings > Paper > Media Conﬁguration > Universal Setup. Conﬁgure the settings. Loading trays CAUTION—TIPPING HAZARD: To reduce the risk of equipment instability, load each tray separately. Keep all other trays closed until needed.
Page 28 Set up, install, and conﬁgure Flex, fan, and align the paper edges before loading. Load the paper stack with the printable side facedown, and then make sure that the guides ﬁt snugly against the paper. Notes: • Load letterhead facedown with the header toward the front of the tray for one‑sided printing. •...
Page 29 Set up, install, and conﬁgure Loading the multipurpose feeder Open the multipurpose feeder. Flex, fan, and align the paper edges before loading. Load paper with the printable side faceup. Notes: • Load letterhead faceup with the header toward the rear of the printer for one‑sided printing. •...
Page 30 Set up, install, and conﬁgure Adjust the guide to match the size of the paper that you are loading. From the control panel, set the paper size and paper type to match the paper loaded. Linking trays From the home screen, touch Settings > Paper > Tray Conﬁguration > select a paper source. Set the same paper size and paper type for the trays that you are linking.
Page 31 Set up, install, and conﬁgure Adding printers to a computer Before you begin, do one of the following: • Connect the printer and the computer to the same network. For more information on connecting the printer to a network, see “Connecting the printer to a Wi‑Fi network”...
Page 32 Set up, install, and conﬁgure Updating ﬁrmware To enhance printer performance and ﬁx issues, update the printer ﬁrmware regularly. For more information on updating the ﬁrmware, contact your sales representative. Open a web browser, and then type the printer IP address in the address ﬁeld. Notes: •...
Page 33 Set up, install, and conﬁgure Navigate to the Conﬁguration tab, and then select Update Now ‑ Ask Printer. Apply the changes. For Macintosh users From System Preferences in the Apple menu, navigate to your printer, and then select Options & Supplies. Navigate to the list of hardware options, and then add any installed options.
Page 34 Set up, install, and conﬁgure Installing optional trays CAUTION—SHOCK HAZARD: To avoid the risk of electrical shock, if you are accessing the controller board or installing optional hardware or memory devices sometime after setting up the printer, then turn the printer off, and unplug the power cord from the electrical outlet before continuing. If you have any other devices attached to the printer, then turn them off as well, and unplug any cables going into the printer.
Page 35 Set up, install, and conﬁgure Using a ﬂat‑head screwdriver, open the controller board access cover. Warning—Potential Damage: Controller board electronic components are easily damaged by static electricity. Touch a metal surface on the printer before touching any controller board components or connectors.
Page 36 Set up, install, and conﬁgure Locate the ISD connector. Insert the ISD to its connector.
Page 37 Set up, install, and conﬁgure Close the controller board access cover, and then install the screw. Connect the power cord to the printer, and then to the electrical outlet. CAUTION—POTENTIAL INJURY: To avoid the risk of ﬁre or electrical shock, connect the power cord to an appropriately rated and properly grounded electrical outlet that is near the product and easily accessible.
Page 38 Set up, install, and conﬁgure Using a ﬂat‑head screwdriver, open the controller board access cover. Warning—Potential Damage: Controller board electronic components are easily damaged by static electricity. Touch a metal surface on the printer before touching any controller board components or connectors.
Page 39 Set up, install, and conﬁgure Attach the hard disk interface cable to the controller board.
Page 40 Set up, install, and conﬁgure Close the controller board access cover, and then install the screw. Connect the power cord to the printer, and then to the electrical outlet. CAUTION—POTENTIAL INJURY: To avoid the risk of ﬁre or electrical shock, connect the power cord to an appropriately rated and properly grounded electrical outlet that is near the product and easily accessible.
Page 41 Set up, install, and conﬁgure Unpack the internal solutions port (ISP) kit. • RS-232C Serial Interface Card • Parallel 1284-B Interface Card • MarkNet N8230 Fiber Ethernet ISP extended cable Mounting bracket Thumbscrews Housing Remove the preinstalled interface cable from the ISP.
Page 42 Set up, install, and conﬁgure Install the ISP into its housing. Secure the ISP in place, and then attach the ISP extended cable.
Page 43 Set up, install, and conﬁgure Using a ﬂat‑head screwdriver, remove the controller board access cover. Warning—Potential Damage: Controller board electronic components are easily damaged by static electricity. Touch a metal surface on the printer before touching any controller board electronic components or connectors.
Page 44 Set up, install, and conﬁgure Note: Hard disk is supported only in some printer models. Disconnect the hard disk interface cable from the controller board. Connect the hard disk interface cable to the ISP. Connect the ISP extended cable to the ISP connector.
Page 45 Set up, install, and conﬁgure Close the ISP kit, and then install the screw. Connect the power cord to the printer, and then to the electrical outlet. CAUTION—POTENTIAL INJURY: To avoid the risk of ﬁre or electrical shock, connect the power cord to an appropriately rated and properly grounded electrical outlet that is near the product and easily accessible.
Page 46 Set up, install, and conﬁgure Connecting the printer to a wireless network using Wi‑Fi Protected Setup (WPS) Before you begin, make sure that: • The access point (wireless router) is WPS‑certiﬁed or WPS‑compatible. For more information, see the documentation that came with your access point. •...
Page 47 Set up, install, and conﬁgure • Show Password on Setup Page—Shows the password on the Network Setup Page. • Auto-Accept Push Button Requests—Lets the printer accept connection requests automatically. Note: Accepting push‑button requests automatically is not secured. Notes: • By default, the Wi-Fi Direct network password is not visible on the printer display. To show the password, enable the password peek icon.
Page 48 Set up, install, and conﬁgure For Macintosh users Click the wireless icon, and then select the printer Wi‑Fi Direct name. Note: The string DIRECT-xy (where x and y are two random characters) is added before the Wi-Fi Direct name. Type the Wi‑Fi Direct password. Note: Switch your computer back to its previous network after disconnecting from the Wi-Fi Direct network.
Page 49 Secure the printer Secure the printer Locating the security slot The printer is equipped with a security lock feature. Attach a security lock compatible with most laptop computers in the location shown to secure the printer in place. Erasing printer memory To erase volatile memory or buffered data in your printer, turn off the printer.
Page 50 Secure the printer Restoring factory default settings From the home screen, touch Settings > Device > Restore Factory Defaults. Touch Restore Settings > select the settings that you want to restore > RESTORE. Start the operation. Statement of Volatility Type of memory Description Volatile memory The printer uses standard random access memory (RAM)
Page 51 Print Print Printing from a computer Note: For labels, card stock, and envelopes, set the paper size and type in the printer before printing the document. From the document that you are trying to print, open the Print dialog. If necessary, adjust the settings. Print the document.
Page 52 Print Printing from a mobile device using Wi‑Fi Direct® ® Wi‑Fi Direct is a printing service that lets you print to any Wi‑Fi Direct‑ready printer. Note: Make sure that the mobile device is connected to the printer wireless network. For more information, “Connecting a mobile device to the printer”...
Page 53 Print Warning—Potential Damage: To avoid loss of data or printer malfunction, do not touch the ﬂash drive or the printer in the area shown while actively printing, reading, or writing from the memory device. Supported ﬂash drives and ﬁle types Flash drives •...
Page 54 Print Setting Description Max Invalid PIN Set the limit for entering an invalid PIN. Note: When the limit is reached, the print jobs for that user name are deleted. Conﬁdential Job Set an individual expiration time for each held job before it is automatically deleted from Expiration the printer memory, hard disk, or intelligent storage drive.
Page 55 Print Click Print. From the printer home screen, release the print job. Touch Held jobs > select your computer name > Conﬁdential > enter the PIN > select the print job > Print. Using the print driver With a document open, choose File > Print. Select a printer, and then from the drop-down menu following the Orientation menu, choose Print and Hold.
Page 56 Use printer menus Use printer menus Menu map Device • • Preferences Accessibility • • Eco‑Mode Restore Factory Defaults • • Remote Operator Panel Maintenance • • Notiﬁcations Home Screen Customization • • Power Management Update Firmware • • Anonymous Data Collection About this Printer Print •...
Page 57 Use printer menus Device Preferences Menu item Description Display Language Set the language of the text that appears on the display. [List of languages] Country/Region Identify the country or region where the printer is conﬁgured to operate. [List of countries or regions] Run initial setup Run the setup wizard.
Page 58 Use printer menus Menu item Description Flash Drive Access Enable access to the ﬂash drive. Disabled Enabled* Device Sounds Conﬁgure the sound settings of the printer. Mute All Sounds (Off*) Note: This menu item appears only in some printer models. Button Feedback (On*) Volume (5*) Alarm Control (Single*)
Page 59 Use printer menus Remote Operator Panel Menu item Description External VNC Connection Connect an external Virtual Network Computing (VNC) client to the remote control panel. Don’t Allow* Allow Authentication Type Set the authentication type when accessing the VNC client server. None* Standard Authentication VNC Password...
Page 60 Use printer menus Menu item Description E‑mail Alerts Setup Type the server IP address or host name of your secondary or backup SMTP server. E‑mail Setup Secondary SMTP Gateway E‑mail Alerts Setup Enter the server port number of your secondary or backup SMTP server.
Page 61 Use printer menus Menu item Description E‑mail Alerts Setup Specify the password to connect to the SMTP server. E‑mail Setup Device Password E‑mail Alerts Setup Specify the realm for the Kerberos 5 authentication protocol. E‑mail Setup Kerberos 5 REALM E‑mail Alerts Setup Specify the domain name for the NTLM security protocol.
Page 62 Use printer menus Menu item Description Error Prevention Set the printer to show a message when a short paper error occurs. Display Short Paper Error Note: Short paper refers to the size of the paper loaded. Auto‑clear* Error Prevention Set the printer to process the entire page into the memory before printing it.
Page 63 Use printer menus Menu item Description Timeouts Set the time before the printer turns off. Hibernate Timeout Disabled 1 hour 2 hours 3 hours 6 hours 1 day 2 days 3 days* 1 week 2 weeks 1 month Timeouts Set Hibernate Timeout to turn off the printer while an active Ethernet connection exists.
Page 64 Use printer menus Menu item Description Key Repeat Initial Delay Set the initial length of delay in seconds before a repeating key starts repeating. 0.25–5 (1*) Note: This menu item appears only when a keyboard is attached to the printer. Key Repeat Rate Set the number of presses per second for a repeating key.
Page 65 Use printer menus Maintenance Conﬁguration Menu Menu item Description USB Conﬁguration Change the USB driver mode of the printer to improve its compatibility with a personal computer. USB PnP USB Conﬁguration Set the USB port to run at full speed and disable its high‑speed capabilities.
Page 66 Use printer menus Menu item Description Tray Conﬁguration Set the tray to support multiple universal sizes. Multiple Universal Sizes Off* Reports Print reports about printer menu settings, status, and event logs. Menu Settings Page Event Log Event Log Summary Supply Usage And Counters Reset the supply usage history to the factory default level.
Page 67 Use printer menus Menu item Description Device Operations Set the printer to operate in Quiet Mode. Quiet Mode Note: Enabling this setting slows down the overall Off* performance of the printer. Device Operations Set the printer to operate in a special mode, in which it attempts to continue offering as much functionality as possible, despite Safe Mode known issues.
Page 68 Use printer menus Menu Description Status/Supplies Specify which icons to show on the home screen. Job Queue Settings Address Book USB Drive Held Jobs Update ﬁrmware Menu item Description Current Version Show the current ﬁrmware version installed on the printer. Check for updates now Check for ﬁrmware updates.
Page 69 Use printer menus Menu item Description Flip Style Determine which side of the paper is bound when performing two‑sided printing. Long Edge* Short Edge Blank Pages Print blank pages that are included in a print job. Print Do Not Print* Collate Keep the pages of a print job stacked in sequence, particularly when printing multiple copies of the job.
Page 70 Use printer menus Menu item Description Print Area Set the printable area on a sheet of paper. Normal* Whole Page Note: An asterisk (*) next to a value indicates the factory default setting. Setup Menu item Description Printer Language Set the printer language. PCL Emulation* Note: Setting a printer language default does not prevent a software PS Emulation...
Page 71 Use printer menus Quality Menu item Description Print Resolution Set the resolution for the printed output. 600 dpi 1200 Image Q* 2400 Image Q 1200 dpi 300 dpi Pixel Boost Enable more pixels to print in clusters for clarity, to enhance images horizontally or vertically or to enhance fonts.
Page 72 Use printer menus Menu item Description Log Action at End of Frequency Specify how the printer responds when the frequency threshold expires. None* Note: The value deﬁned in Accounting Log Frequency determines when this E‑mail Current Log action is triggered. E‑mail &...
Page 73 Use printer menus Menu item Description Scale To Fit Scale the page content to ﬁt the selected paper size. Off* Annotations Specify whether to print annotations in the PDF. Print Do Not Print* Print PDF Error Enable the printing of PDF error. Note: An asterisk (*) next to a value indicates the factory default setting.
Page 74 Use printer menus Menu item Description Font Source Select the source which contains the default font selection. Resident* Notes: Disk • Disk and Flash appear only when a hard disk or an intelligent storage Download drive (ISD) that contains fonts is installed. Flash •...
Page 75 Use printer menus Menu item Description Auto CR after LF Set the printer to perform a carriage return after a line feed control command. Off* Note: Carriage return is a mechanism that commands the printer to move the position of the cursor to the ﬁrst position on the same line. Auto LF after CR Set the printer to perform a line feed after a carriage return control command.
Page 76 Use printer menus Menu item Description Orientation Specify the orientation of text and graphics on the page. Portrait* Landscape Reverse Portrait Reverse Landscape Note: An asterisk (*) next to a value indicates the factory default setting. Paper Tray Conﬁguration Menu item Description Default Source Set the paper source for all print jobs.
Page 77 Use printer menus Media Conﬁguration Universal Setup Menu item Description Units of Measure Specify the unit of measurement for the universal paper. Inches Note: Inches is the U.S. factory default setting. Millimeters is the Millimeters international factory default setting. Portrait Width Set the portrait width of the universal paper.
Page 78 Use printer menus USB Drive Flash Drive Print Menu item Description Number of Copies Set the number of copies. 1–9999 (1*) Paper Source Set the paper source for the print job. Tray [x] (1*) Multipurpose Feeder Manual Paper Manual Envelope Collate Keep the pages of a print job stacked in sequence, particularly when printing multiple copies of the job.
Page 79 Use printer menus Menu item Description Separator Sheets Insert blank separator sheets when printing. Off* Between Copies Between Jobs Between Pages Separator Sheet Source Specify the paper source for the separator sheet. Tray [x] (1*) Multipurpose Feeder Blank Pages Print blank pages in a print job. Do Not Print* Print Note: An asterisk (*) next to a value indicates the factory default setting.
Page 80 Use printer menus Menu item Description Enable Network Connections Enable the printer to connect to a network. Enable LLDP Enable Link Layer Discovery Protocol (LLDP) in the printer. Off* Note: An asterisk (*) next to a value indicates the factory default setting. Wireless Note: This menu is available only in printers connected to a Wi‑Fi network or printers that have a wireless network adapter.
Page 81 Use printer menus Menu item Description Wireless Security Mode Set the security mode for connecting the printer to Wi‑Fi devices. Disabled* WPA2/WPA-Personal WPA2-Personal WPA2/WPA3 ‑ Personal WPA3 ‑ Personal 802.1x - RADIUS WPA2/WPA Personal Enable Wi‑Fi security through Wi-Fi Protected Access (WPA). AES* Note: This menu item appears only when the Wireless Security Mode is set to WPA2/WPA-Personal.
Page 82 Use printer menus Menu item Description Network Address View the network addresses. PCL SmartSwitch Set the printer to switch automatically to PCL emulation when a print job requires it, regardless of the default printer language. Note: If PCL SmartSwitch is off, then the printer does not examine incoming data and uses the default printer language speciﬁed in the Setup menu.
Page 83 Use printer menus Menu item Description Auto‑Accept Push Button Accept requests to connect to the network automatically. Requests Note: Accepting clients automatically is not secured. Off* Note: An asterisk (*) next to a value indicates the factory default setting. AirPrint Note: This menu appears only in the Embedded Web Server.
Page 84 Use printer menus Menu item Description Enable Mopria Print Discovery Allow Mopria‑enabled devices to discover the printer. Note: An asterisk (*) next to a value indicates the factory default setting. Ethernet Menu item Description Network Speed Show the speed of the active network adapter. IPv4 Conﬁgure the IPv4 settings.
Page 85 Use printer menus Menu item Description Mac Binary PS Set the printer to process Macintosh binary PostScript print jobs. Auto* Notes: • Auto processes print jobs from computers using either Windows or Macintosh operating systems. • Off ﬁlters PostScript print jobs using the standard protocol. Energy Efficient Ethernet Reduce power consumption when the printer does not receive data from the Ethernet network.
Page 86 Use printer menus Menu item Description Enable mDNS Update the multicast DNS settings. WINS Server Address Specify a server address for Windows Internet Name Service (WINS). Enable BOOTP Allow the BOOTP to assign a printer IP address. Off* Restricted Server List Specify the IP addresses that are allowed to communicate with the printer over TCP/IP.
Page 87 Use printer menus Menu item Description SNMP Versions 1 and 2c Conﬁgure Simple Network Management Protocol (SNMP) versions 1 and 2c to install print drivers and applications. Enabled Allow SNMP Set Enable PPM MIB SNMP Community SNMP Version 3 Conﬁgure SNMP version 3 to install and update the printer security. Enabled Context Name Set Read/Write Credentials...
Page 88 Use printer menus Menu item Description Enable IPSec Enable Internet Protocol Security (IPSec). Off* Base Conﬁguration Set the IPSec base conﬁguration. Default* Note: This menu item appears only when Enable IPSec is set to Compatibility Secure DH (Diffie‑Hellman) Group Proposal Set the IPSec base conﬁguration.
Page 89 Use printer menus 802.1x Note: This menu appears only in network printers or printers that are attached to print servers. Menu item Description Active Let the printer join networks that require authentication before allowing access. Off* 802.1x Authentication Conﬁgure the settings for authenticating the 802.1x connection. Device Login Name Device Login Password Validate Serve Certiﬁcate (On*)
Page 90 Use printer menus HTTP/FTP Settings Menu item Description Proxy Conﬁgure the HTTP and FTP server settings. HTPP Proxy IP Address HTTP Default IP Port FTP Proxy IP Address FTP Default IP Port Authentication User Name Password Local Domains Other Settings Access the Embedded Web Server to monitor and manage the printer.
Page 91 Use printer menus Menu item Description PCL SmartSwitch Set the printer to switch to PCL emulation when a print job received through a USB port requires it, regardless of the default printer language. Note: When this setting is disabled, the printer does not examine incoming data and uses the default printer language speciﬁed in the Setup menu.
Page 92 Use printer menus Security Login Methods Manage Permissions Menu item Description Function Access Control access to the printer functions. Modify Address Book Manage Shortcuts Create Proﬁles Manage Bookmarks Flash Drive Print Held Jobs Access Use Proﬁles Cancel Jobs at the Device Change Language Internet Printing Protocol (IPP) B/W Print...
Page 93 Use printer menus Local Accounts Menu item Description Manage Groups/Permissions Control group or user access to the printer functions, applications, and security settings. Add Group Import Access Controls Function Access Administrative Menus Device Management Apps All Users Import Access Controls Function Access Administrative Menus Device Management...
Page 94 Use printer menus Security Audit Log Menu item Description Enable Audit Record the events in the secure audit log and remote syslog. Off* Enable Remote Syslog Send audit logs to a remote server. Off* Remote Syslog Server Specify the remote syslog server. Remote Syslog Port Specify the remote syslog port.
Page 95 Use printer menus Menu item Description Severity of Events to Log Specify the priority level cutoff for logging messages and events. 0 ‑ Emergency 1 ‑ Alert 2 ‑ Critical 3 ‑ Error 4 ‑ Warning* 5 ‑ Notice 6 ‑ Informational 7 ‑...
Page 96 Use printer menus Menu item Description Digitally Sign Exports Add a digital signature to each exported log ﬁle. Off* Clear Log Delete all audit logs. Export Log Export a security log to a ﬂash drive. Syslog (RFC 5424) Syslog (RFC 3164) Note: An asterisk (*) next to a value indicates the factory default setting.
Page 97 Use printer menus Conﬁdential Print Setup Menu item Description Max Invalid PIN Set the limit for entering an invalid PIN. 2–10 Note: When the limit is reached, the print jobs for that user name are deleted. Conﬁdential Job Expiration Set an individual expiration time for each held job before it is automatically deleted from the hard disk or intelligent storage drive.
Page 98 Use printer menus Menu item Description Hard Disk Show the encryption status of the hard disk or intelligent storage drive. Intelligent Storage Drive Erase Temporary Data Files Menu item Description Stored in onboard memory Delete all ﬁles stored on the printer memory. Off* Note: An asterisk (*) next to a value indicates the factory default setting.
Page 99 Use printer menus Menu item Description Security Reset Jumper Specify user access to the printer. Enable “Guest” access* Notes: No Effect • Enable "Guest" access allows for device recovery if the admin password is lost. If this issue occurs, then contact customer support. •...
Page 100 Use printer menus Print Menu item Description Print Fonts Print samples and information about the fonts that are available in each printer language. PCL Fonts PS Fonts Print Demo Print a page that shows the printer capabilities and supported solutions. Demo Page Print Directory Print the resources that are stored in the ﬂash drive, hard disk, or intelligent...
Page 101 Use printer menus Menu item Description Print Port and Filter Settings Enable Forms Merge to process all data that are sent to the network port. Network Port Print Port and Filter Settings Specify the network ﬁlter for all data sent to the printer. Network Filter Disabled* NULL...
Page 102 Use printer menus Printing the Menu Settings Page From the home screen, touch Settings > Reports > Menu Settings Page.
Page 103 Maintain the printer Maintain the printer Checking the status of parts and supplies From the home screen, touch Status/Supplies. Select the parts or supplies that you want to check. Note: You can also access this setting by touching the top section of the home screen. Conﬁguring supply notiﬁcations Open a web browser, and then type the printer IP address in the address ﬁeld.
Page 104 Maintain the printer Viewing reports From the home screen, touch Settings > Reports. Select the report that you want to view. Ordering parts and supplies To order supplies, contact the place where you purchased the printer. Note: All life estimates for printer supplies assume printing on letter‑ or A4‑size plain paper. Warning—Potential Damage: Failure to maintain optimum printer performance, or to replace parts and supplies, may cause damage to your printer.
Page 105 Maintain the printer Replacing parts and supplies Replacing the toner cartridge Open door A. Remove the used toner cartridge. Unpack the new toner cartridge.
Page 106 Maintain the printer Shake the toner cartridge to redistribute the toner. Insert the new toner cartridge. Close door A.
Page 107 Maintain the printer Replacing the imaging unit Open door A. Remove the toner cartridge. Remove the used imaging unit. Unpack the new imaging unit.
Page 108 Maintain the printer Shake the imaging unit to redistribute the toner. Warning—Potential Damage: Do not expose the imaging unit to direct light for more than 10 minutes. Extended exposure to light may cause print quality problems. Warning—Potential Damage: Do not touch the photoconductor drum. Doing so may affect the quality of future print jobs.
Page 109 Maintain the printer Insert the new imaging unit. Insert the toner cartridge. Close door A. Replacing MarkNet N8450 Wireless Print Server CAUTION—SHOCK HAZARD: To avoid the risk of electrical shock, if you are accessing the controller board or installing optional hardware or memory devices sometime after setting up the printer, then turn the printer off, and unplug the power cord from the electrical outlet before continuing.
Page 110 Maintain the printer Warning—Potential Damage: Controller board electronic components are easily damaged by static electricity. Touch a metal surface on the printer before touching any controller board components or connectors. Remove the wireless print server cover.
Page 111 Maintain the printer Remove the used wireless print server. Unpack the new wireless print server. Insert the new wireless print server until it clicks into place.
Page 112 Maintain the printer Attach the wireless print server cover, and then install the screw. Close the controller board access cover, and then install the screw.
Page 113 Maintain the printer Connect the power cord to the printer, and then to the electrical outlet. CAUTION—POTENTIAL INJURY: To avoid the risk of ﬁre or electrical shock, connect the power cord to an appropriately rated and properly grounded electrical outlet that is near the product and easily accessible.
Page 114 Maintain the printer Remove the used pick tires. Unpack the new pick tires.
Page 115 Maintain the printer Insert the new pick tires. Insert the tray. Connect the power cord to the printer, and then to the electrical outlet. CAUTION—POTENTIAL INJURY: To avoid the risk of ﬁre or electrical shock, connect the power cord to an appropriately rated and properly grounded electrical outlet that is near the product and easily accessible.
Page 116 Maintain the printer Cleaning printer parts Cleaning the printer CAUTION—SHOCK HAZARD: To avoid the risk of electrical shock when cleaning the exterior of the printer, unplug the power cord from the electrical outlet and disconnect all cables from the printer before proceeding.
Page 117 Maintain the printer Saving energy and paper Conﬁguring the power save mode settings Sleep mode From the home screen, touch Settings > Device > Power Management > Timeouts > Sleep Mode. Specify the amount of time that the printer stays idle before it enters Sleep Mode. Hibernate mode From the home screen, touch Settings >...
Page 118 Maintain the printer • If the printer has separate ﬂoor-standing optional trays or output options attached to it, then disconnect them before moving the printer. • If the printer has a caster base, then carefully roll it to the new location. Use caution when passing over thresholds and breaks in ﬂooring.
Page 119 Troubleshoot a problem Troubleshoot a problem Print quality problems Find the image that resembles the print quality problem you are having, and then click the link below it to read problem-solving steps. “Blank or white pages” on “Dark print” on page 120 “Fine lines are not printed “Folded or wrinkled paper”...
Page 120 Troubleshoot a problem “Vertical dark lines or “Vertical dark streaks with “Vertical light bands” on “Vertical white lines” on streaks” on page 138 print missing” on page 135 page 136 page 139 Printing problems Print quality is poor Blank or white pages Note: Before solving the problem, print the Print Quality Test Pages.
Page 121 Troubleshoot a problem Action Step 2 Go to step 3. The problem is solved. Remove any packing material that is left on the imaging unit. Remove the toner cartridge, and then remove the imaging unit. Warning—Potential Damage: Do not expose the imaging unit to direct light for more than 10 minutes.
Page 122 Troubleshoot a problem Action Step 1 Go to step 2. The problem is solved. Check if the printer is using a genuine and supported toner cartridge. Note: If the cartridge is not supported, then install a supported one. Print the document. Is the print dark? Step 2 Go to step 3.
Page 123 Troubleshoot a problem Action Step 6 Go to step 7. The problem is solved. Load paper from a fresh package. Note: Paper absorbs moisture due to high humidity. Store paper in its original wrapper until you are ready to use it. Print the document.
Page 124 Troubleshoot a problem Action Step 1 The problem is Go to step 2. solved. Check if the printer is using a genuine and supported toner cartridge. Note: If the cartridge is not supported, then install a supported one. Print the document. Are ﬁne lines printed correctly? Step 2 The problem is...
Page 125 Troubleshoot a problem Action Step 2 Go to step 3. The problem is solved. Load paper from a fresh package. Note: Paper absorbs moisture due to high humidity. Store paper in its original wrapper until you are ready to use it. Print the document.
Page 126 Troubleshoot a problem Action Step 2 Go to step 3. The problem is solved. Check if the printer is using a genuine and supported toner cartridge. Note: If the cartridge is not supported, then install a supported one. Print the document. Does gray background appear on prints? Step 3 Go to step 4.
Page 127 Troubleshoot a problem Incorrect margins Note: Before solving the problem, print the Print Quality Test Pages. From the home screen, touch Settings > Troubleshooting > Print Quality Test Pages. Action Step 1 The problem is Go to step 2. solved. Adjust the paper guides in the tray to the correct position for the paper loaded.
Page 128 Troubleshoot a problem Action Step 1 Go to step 2. The problem is solved. Check if the printer is using a genuine and supported toner cartridge. Note: If the cartridge is not supported, then install a supported one. Print the document. Is the print light? Step 2 Go to step 3.
Page 129 Troubleshoot a problem Action Step 5 Go to step 6. The problem is solved. Remove the imaging unit. Warning—Potential Damage: Do not expose the imaging unit to direct light. Extended exposure to light can cause print quality problems. Warning—Potential Damage: Do not touch the photoconductor drum.
Page 130 Troubleshoot a problem Action Step 1 Go to step 2. The problem is solved. Check if the printer is using a genuine and supported toner cartridge. Note: If the cartridge is not supported, then install a supported one. Print the document. Is the print mottled? Step 2 Go to step 4.
Page 131 Troubleshoot a problem Action Step 1 Go to step 2. The problem is solved. Check if the printer is using a genuine and supported toner cartridge. Note: If the cartridge is not supported, then install a supported one. Print the document. Is the paper curled? Step 2 Go to step 3.
Page 132 Troubleshoot a problem Print crooked or skewed Note: Before solving the problem, print the Print Quality Test Pages. From the home screen, touch Settings > Troubleshooting > Print Quality Test Pages. Action Step 1 Go to step 2. The problem is solved.
Page 133 Troubleshoot a problem Action Step 1 Go to step 2. The problem is solved. Check if the printer is using a genuine and supported toner cartridge. Note: If ther cartridge is not supported, then install a supported one. Print the document. Is the printer printing solid black pages? Step 2 Go to step 3.
Page 134 Troubleshoot a problem Note: Before solving the problem, print the Print Quality Test Pages. From the home screen, touch Settings > Troubleshooting > Print Quality Test Pages. Action Step 1 Go to step 2. The problem is solved. Check if the printer is using a genuine and supported toner cartridge.
Page 135 Troubleshoot a problem Action Step 1 Go to step 2. The problem is solved. Check if the printer is using a genuine and supported toner cartridge. Note: If the cartridge is not supported, then install a supported one. Print the document. Does toner easily rub off? Step 2 Contact...
Page 136 Troubleshoot a problem Action Step 2 Go to step 3. The problem is solved. Remove, and then insert the imaging unit. Warning—Potential Damage: Do not expose the imaging unit to direct light. Extended exposure to light may cause print quality problems. Warning—Potential Damage: Do not touch the photoconductor drum.
Page 137 Troubleshoot a problem Vertical white lines Note: Before solving the problem, print the Print Quality Test Pages. From the home screen, touch Settings > Troubleshooting > Print Quality Test Pages. Action Step 1 Go to step 2. The problem is solved.
Page 138 Troubleshoot a problem Action Step 1 Go to step 2. The problem is solved. Check if the printer is using a genuine and supported toner cartridge. Note: If the cartridge is not supported, then install a supported one. Print the document. Do vertical dark bands appear on prints? Step 2 Go to step 3.
Page 139 Troubleshoot a problem Vertical dark lines or streaks Note: Before solving the problem, print the Print Quality Test Pages. From the home screen, touch Settings > Troubleshooting > Print Quality Test Pages. Action Step 1 Go to step 2. The problem is solved.
Page 140 Troubleshoot a problem Vertical dark streaks with print missing Note: Before solving the problem, print the Print Quality Test Pages. From the home screen, touch Settings > Troubleshooting > Print Quality Test Pages. Action Step 1 Go to step 2. The problem is solved.
Page 141 Troubleshoot a problem Note: Before solving the problem, print the Print Quality Test Pages. From the home screen, touch Settings > Troubleshooting > Print Quality Test Pages. Action Step 1 Go to step 2. Take note of the distance, and then Using the Print Quality Test Pages, check if the distance between contact customer...
Page 142 Troubleshoot a problem Action Step 4 The problem is Go to step 5. solved. Turn off the printer, wait for about 10 seconds, and then turn on the printer. Print the document. Is the document printed? Step 5 The problem is Contact customer solved.
Page 143 Troubleshoot a problem Action Step 3 The problem is Go to step 4. solved. If you are printing from the Internet, then the printer may be reading the multiple job titles as duplicates. For Windows users Open the Printing Preferences dialog. From the Print and Hold tab, click Use Print and Hold, and then click Keep duplicate documents.
Page 144 Troubleshoot a problem Action Step 2 The problem is Go to step 3. solved. Depending on your operating system, specify the paper size and paper type from the Printing Preferences or Print dialog. Note: You can also change the settings on the printer control panel.
Page 145 Troubleshoot a problem Action Step 4 Go to step 5. The problem is solved. From the home screen, touch Settings > Print > Quality > Print Resolution. Set the resolution to 600 dpi. Print the document. Is the printer printing slow? Step 5 Go to step 6.
Page 146 Troubleshoot a problem Action Step 8 Contact customer The problem is support. solved. Make sure that the printer is not overheating. Notes: • Allow the printer to cool down after a long print job. • Observe the recommended ambient temperature for the printer.
Page 147 Troubleshoot a problem Action Step 6 The problem is Go to step 7. solved. Turn off the printer, install the hardware options, and then turn on the printer. For more information, see the documentation that came with the option. Is the printer responding? Step 7 The problem is Go to step 8.
Page 148 Troubleshoot a problem Action Step 5 Go to step 7. Go to step 6. Check if the ﬂash drive is supported. For more information, see “Supported ﬂash drives and ﬁle types” on page Is the ﬂash drive supported? Step 6 The problem is Go to step 7.
Page 149 Troubleshoot a problem • Do not slide paper into the tray. Load paper as shown in the illustration. • Make sure that the paper guides are positioned correctly and are not pressing tightly against the paper or envelopes. • Push the tray ﬁrmly into the printer after loading paper. Use recommended paper •...
Page 150 Troubleshoot a problem Jam locations Multipurpose feeder Trays Door A Duplex unit Door B...
Page 151 Troubleshoot a problem Paper jam in door A Open door A. Remove the toner cartridge. Remove the imaging unit. Warning—Potential Damage: Do not expose the imaging unit to direct light for more than 10 minutes. Extended exposure to light may cause print quality problems.
Page 152 Troubleshoot a problem Warning—Potential Damage: Do not touch the photoconductor drum. Doing so may affect the quality of future print jobs. Remove the jammed paper. CAUTION—HOT SURFACE: The inside of the printer might be hot. To reduce the risk of injury from a hot component, allow the surface to cool before touching it.
Page 153 Troubleshoot a problem Insert the toner cartridge. Note: Use the arrows inside the printer as guides. Close door A. Paper jam in door B Open door B. CAUTION—HOT SURFACE: The inside of the printer might be hot. To reduce the risk of injury from a hot component, allow the surface to cool before touching it.
Page 154 Troubleshoot a problem Remove the jammed paper. Note: Make sure that all paper fragments are removed. Close door B.
Page 155 Troubleshoot a problem Paper jam in the duplex unit Remove the tray. Push the duplex unit latch to open the duplex unit. Remove the jammed paper. Note: Make sure that all paper fragments are removed.
Page 156 Troubleshoot a problem Insert the tray. Paper jam in trays Remove the tray. Warning—Potential Damage: To prevent damage from electrostatic discharge, touch any exposed metal frame of the printer before accessing or touching interior areas of the printer. Remove the jammed paper. Note: Make sure that all paper fragments are removed.
Page 157 Troubleshoot a problem Insert the tray. Paper jam in the multipurpose feeder Remove paper from the multipurpose feeder. Remove the jammed paper. Note: Make sure that all paper fragments are removed. Reload paper, and then adjust the paper guide. Network connection problems Cannot open Embedded Web Server Action Step 1...
Page 158 Troubleshoot a problem Action Step 2 The problem is Go to step 3. solved. Make sure that the printer IP address is correct. Notes: • View the IP address on the home screen. • An IP address appears as four sets of numbers separated by periods, such as 123.123.123.123.
Page 159 Troubleshoot a problem Cannot connect the printer to the Wi‑Fi network Action Step 1 The problem is Go to step 2. solved. Make sure that Active Adapter is set to Auto. From the home screen, touch Settings > Network/Ports > Network Overview >...
Page 160 Troubleshoot a problem Hardware options problems Cannot detect internal option Action Step 1 The problem is Go to step 2. solved. Turn off the printer, wait for about 10 seconds, and then turn on the printer. Does the printer detect the internal option? Step 2 Go to step 4.
Page 161 Troubleshoot a problem • Cancel the current print job. Not enough free space in ﬂash memory for resources Try one or more of the following: • Touch Continue to clear the message and continue printing. • Delete fonts, macros, and other data stored in the ﬂash memory. •...
Page 162 Troubleshoot a problem Paper feed problems Envelope seals when printing Action Step 1 Go to step 2. The problem is solved. Use an envelope that has been stored in a dry environment. Note: Printing on envelopes with high moisture content can seal the ﬂaps.
Page 163 Troubleshoot a problem Tray linking does not work Action Step 1 The problem is Go to step 2. solved. Check if the trays contain the same paper size and paper type. Check if the paper guides are positioned correctly. Print the document. Do the trays link correctly? Step 2 The problem is...
Page 164 Troubleshoot a problem Action Step 2 Go to step 3. The problem is solved. From the home screen, touch Settings > Paper > Tray Conﬁguration > Paper Size/Type. Set the correct paper size and type. Print the document. Do paper jams occur frequently? Step 3 Contact customer...
Page 165 Notices Notices Product information Product name: Mono Laser Printers Machine type: 4602 Models: 480, 680, 685, and their equivalent models Edition notice July 2023 The following paragraph does not apply to any country where such provisions are inconsistent with local law: THIS PUBLICATION IS PROVIDED “AS IS”...
Page 166 Notices 1-meter average sound pressure, dBA Printing One-sided: 55 (4602-480); 56 (4602-680; 4602-685) Two-sided: 55 Ready Waste from Electrical and Electronic Equipment (WEEE) directive The WEEE logo signiﬁes speciﬁc recycling programs and procedures for electronic products in countries of the European Union.
Page 167 Notices Lithium‑ion rechargeable battery This product may contain a coin-cell, lithium-ion rechargeable battery, which should only be removed by a trained technician. Crossed-out wheelie bin means the product should not be discarded as unsorted waste but must be sent to separate collection facilities for recovery and recycling. In the event the battery is removed, do not dispose of the battery in your household waste.
Page 168 Notices ENERGY STAR ® Any product bearing the ENERGY STAR emblem on the product or on a start-up screen is certiﬁed to comply with Environmental Protection Agency (EPA) ENERGY STAR requirements as of the date of manufacture. Temperature information Operating temperature and relative humidity 10 to 32.2°C (50 to 90°F) and 15 to 80% RH 15.6 to 32.2°C (60 to 90°F) and 8 to 80% RH Maximum wet-bulb temperature...
Page 169 Notices Power consumption Product power consumption The following table documents the power consumption characteristics of the product. Note: Some modes may not apply to your product. Mode Description Power consumption (Watts) Printing The product is generating hard‑copy output from electronic One-sided: 644 (4602-480);...
Page 170 Notices Hibernate Mode This product is designed with an ultra‑low power operating mode called Hibernate mode. When operating in Hibernate Mode, all other systems and devices are powered down safely. The Hibernate mode can be entered in any of the following methods: •...
Page 171 Notices Modular component notice Wireless models contain the following modular component: AzureWave AW-CM467-SUR; FCC ID:TLZ-CM467; IC:6100A-CM467 To determine which modular components are installed in your particular product, refer to the labeling on your actual product. Exposure to radio frequency radiation The radiated output power of this device is far below the radio frequency exposure limits of the FCC and other regulatory agencies.
Page 172 Notices UK (NI) EU and other countries statement of radio transmitter operational frequency bands and maximum RF power This radio product transmits in either the 2.4GHz (2.412–2.472 GHz in the EU) or 5GHz (5.15–5.35, 5.47–5.725 in the EU) bands. The maximum transmitter EIRP power output, including antenna gain, is ≤ 20dBm for both bands.
Page 173 Notices เครื ่ อ งวิ ท ยุ ค มนาคมนี ้ ม ี ร ะดั บ การแผ ค ลื ่ น แม เ หล็ ก ไฟฟ า สอดคล อ งตามมาตรฐาน ความปลอดภั ย ต อ สุ ข ภาพของมนุ ษ ย จ ากการใช เ ครื ่ อ งวิ ท ยุ ค มนาคมที ่ ค ณะกรรมการกิ จ การ โทรคมนาคมแห...
Page 174 Notices Note: To assure compliance with FCC regulations on electromagnetic interference for a Class B computing device, use a properly shielded and grounded cable such as Lexmark part number 1021231 for parallel attach or 1021294 for USB attach. Use of a substitute cable not properly shielded and grounded may result in a violation of FCC regulations.
Page 175 Notices United Kingdom (UK) conformity This product is in conformity with the protection requirements of the Electromagnetic Compatibility Regulations 2016, the Electrical Equipment (Safety) Regulations 2016, the Ecodesign for Energy-Related Products and Energy Information (Amendment) (EU Exit) Regulations 2019, and the Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Regulations 2012.
Page 176 Index Index clearing jam default speaker volume in door A 150 adjusting 25 activating Voice Guidance 23 in door B 152 defective intelligent storage adding apps to home screen 19 in the duplex unit 154 drive 159 adding contact groups 22 in the multipurpose feeder 156 deleting contact groups 22 adding contacts 22...
Page 177 Index ﬂash drive installing the print driver 29 Certiﬁcate Management 95 printing from 51 installing the printer software 29 Conﬁdential Print Setup 96 folder paper 123 installing trays 33 Conﬁguration Menu 64 font sample list intelligent storage drive 32, 49 Device 98 printing 54 erasing 48...
Page 178 Index USB 90 paper guidelines 11 toner easily rubs off 133 Wireless 79 paper jam in door A 150 vertical dark bands 136 Wi‑Fi Direct 81 paper jam in door B 152 vertical dark streaks with print Menu Settings Page paper jam in the duplex unit 154 missing 139 printing 101...
Page 179 Index printer software security slot touch screen installing 29 locating 48 cleaning 115 printer status 10 selecting location trays printing for the printer 17 installing 33 conﬁdential print jobs 53 separator sheets linking 29 font sample list 54 placing 54 unlinking 29 from a computer 50 serial number, printer...
Page 180 Index vertical dark bands on prints 136 vertical dark lines on prints 138 vertical dark streaks 139 vertical light bands 135 vertical streaks on prints 138 vertical white lines 136 viewing reports 103 Voice Guidance activating 23 deactivating 23 speech rate 25 Voice Guidance speech rate adjusting 25 volatile memory 49...
