MODEL : STm.57w
MOBILE PRINTER
All specifications are subject to change without notice
Rev. 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STm.57w and is the answer not in the manual?

Questions and answers

Related Manuals for Source Technologies STm.57w

Summary of Contents for Source Technologies STm.57w

  • Page 1 MODEL : STm.57w MOBILE PRINTER All specifications are subject to change without notice Rev. 1.0...

  • Page 2: Table Of Contents

    Table of Contents RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTION 1. Unpacking 2. Product overview 3. Installation & Usage 3-1. Control Panel Usage 3-2. Battery Installation 3-3. Battery removel 3-4.

  • Page 3: Unpacking

    1. Unpacking 2. Product overview Standard Front Power switch Printer Battery Belt Buckle Paper feed Cover open button button Charger Connector Recharger Serial Cable USB Shelded Cable Battery Side Roll paper Quick Manual Optional shoulder strap Battery Holder Cigar jack Printer case SERIAL (Cradle)

  • Page 4: Control Panel Usage

    3. Setting Up the Product 3-2. Installing battery 3-1. Control Panel Usage Button Name function Push the Open to the direction as Open the battery cover and push up This button is used to turn the printer on and off. pointed by arrow in the image.

  • Page 5: Battery Removel

    3-3. Battery removel 3-4. Battery Charging ② ① Push the Open into the direction Push up the hook after opening the indicated with the arrow in the image. battery cover. 1. The battery can be charged only when the temperature is 0~40℃ 2.

  • Page 6: Battery Charger Usage

    3-5. Battery charger Usage 3-6 Usage of Cigar Jack Charger for charging Optional Optional ② Printer ① 1. Please press the battery into the holder until you can hear a snapping sound. 2. Insert DC JACK ① into the end completely as the direct shown above. 3.

  • Page 7: Belt Clip Usage

    3-7. Belt clip Usage 3-8. Roll Paper Installation Insert the belt hook screw into the hole of the belt hook. Open the paper cover pressing the open Put the paper in the right direction after button. Insert a sharp tool into the paper adjusting the paper guide matching the paper guide hole and push it in the direction of width.

  • Page 8: Leather Case Usage

    3-9. Leather Case Usage 3-10. Shoulder Strap Usage Optional Optional Put the printer into the leather case Open the Velcro Insert the strap into the hook on Place the end of strap into the hook of following the direction shown in the shoulder strap.

  • Page 9: Self Test

    3-11. Self Test The sample of self test printout Turn off the power pressing the While you are pressing the FEED power button for approximately button, press the power button 3 seconds. NOTE 1. To print ASCII pattern additionally, press the Feed button once more 2.

  • Page 10: Peripherals Connection

    4. Peripherals Connection This product can communicate with other devices via Wifi(802.11b/g) When the printer is installed initially or when you face a problem, you can run the communication and cable. self test and check the information about -Control Circuit, Mechanism, Print Quality, ROM Version 4-1 Wifi(802.11b/g) Connection After checking with self-test and no issues are found, you can examine other devices and software.

  • Page 11: Interface Cable Connection

    5. Printer cleaning 4-2. Interface Cable Connection If the interior of the printer is dusty, printing quality can lowered. In such a case, follow the instructions below to clean up the printer. NOTE 1. Make sure to turn the printer power off prior to cleaning 2.

  • Page 12: Specification

    6. Pritner Specification 6-1. Specification Printing Method Direct Thermal Weight 500g Printing Speed 80mm/sec Environmental sealing IP42 Resolution 203 DPI X 203 DPI Temperature operation 5~40℃ Character ALPHA NUMERIC Character, Extension Character storage -20~60℃ Barcode Code 39, Code 93, UCC/EAN-128, Code 128, Humidity operation 35 ~ 80%...

  • Page 13: Cpcl Command Compatibility

    7. CPCL Command Compatibility NOTE Graphics Compatibility ○ Compatible with only Partially commanders provided Compatible LINE ○ Compatible Compatible by the manufacturer. INVERSE-LINE ○ △ ○ PATTERN ● ○ GRAPHICS ○ ○ Printer Commands Compatibility Advanced Commands Compatibility PRINT ○ CONTRAST ○...
  • Page 14 Line Print Mode Compatibility SETLP ○ SETLF ○ Moving With X and Y Coordinates ○ LMARGIN ○ SETBOLD ○ SETSP ○ Special ASCII Characters ○ SETFF ○ SET-TOF ○ SETLP-TIMEOUT ○...
