  • Page 1 MODEL : STm.58b MOBILE PRINTER All specifications are subject to change without notice Rev. 1.0...

  • Page 2: Table Of Contents

    Table of Contents 1. Unpacking 2. Product overview 3. Usage and Installation 3-1. Control panel usage 3-2. Battery Installation 3-3. Battery removal 3-4. Battery charging 3-5. Battery charger usage 3-6. Usage of Cigar Jack for charging 3-7. Belt clip usage 3-8.

  • Page 3: Unpacking

    1. Unpacking 2. Product overview Standard Front Paper feed button Printer Battery Belt Buckle Open Button Power switch Charger Serial Cable USB Cable Shielded SERIAL Rear Belt clip Roll paper Quick Manual hole Battery Optional DC Power Battery Holder (Cradle) Cigar Jack Charger Shoulder strip Leather case...

  • Page 4: Usage And Installation

    3. Usage and Installation 3-1 Control panel usage 3-2 Battery Installation Hook Button Name function This button is used to turn the printer on and off. Power When the printer is off, press this button for approximately 3 seconds 1. Align battery hook as shown in the picture button and it will turn on the power.

  • Page 5: Battery Removal

    3-4 Battery charging 3-3 Battery removal 180˚ Lamp 1. Be sure that the printer is turned off 2. After open the DC JACK cover, insert DC JACK into the printer. Put up the Belt clip hole turning 180 degree. 3. Plug the power code to electrical outlet. 3-4-1 The status of lamp in charging Status charging...

  • Page 6: Battery Charger Usage

    3-6 Usage of Cigar Jack for charging 3-5 Battery charger usage Optional Optional Lamp Printer DC Jack 1. Insert the battery into the battery holder as shown above 2. Connect the DC JACK to the power electrical outlet. 3. Plug the power code into the electrical outlet. 4.

  • Page 7: Belt Clip Usage

    3-7 Belt Clip usage 3-8 Roll Paper installation Insert the belt clip screw into the hole of Belt clip Press the PUSH button to open Insert the paper in the right the paper cover direction Pull a short length of paper out of Tear off the additional paper using As shown in the picture, tighten the screw with a screw driver.

  • Page 8: Leather Case Usage

    3-10 Self Test 3-9 Leather case usage Optional Turn off the power pressing the While you are pressing the FEED power button for approximately button, press the power button Open the leather case Place the printer into the leather 3 seconds. case NOTE 1.

  • Page 9: Msr Usage

    3-11 MSR usage The sample of self test printout Optional Insert and swipe the card in the direction of the arrow as shown in the picture. When the printer is installed initially or when you face a problem, you can run the self test and check the information about -Control Circuit, Mechanism, Print Quality, ROM Version After checking with self-test and no issues are found, you can examine other...

  • Page 10: Peripherals Connection

    4. Peripherals connection 4-2 Interface Cable Connection This printer can communicate with Peripherals device via Bluetooth and cables. 4-1 Bluetooth Connection Serial 1. Connect USB or Serial cable into the cable connector on the printer. NOTE 1. Printer can be connected to the PDA and PC which can do wireless Use the cable offered by the manufacturer (USB, Serial) communication.

  • Page 11: Specification

    5. Pritner Specification 6.Certification 5-1 Specification FCC Information Printing Method Direct Thermal Printing Speed 80mm/sec This device complies with part 15 of the FCC Results. Operation is Resolution 203 DPI X 203 DPI subject to the following two conditions: Character Font A (12X24), Font B (9X17) (1) This Device may not cause harmful interface, and Character per line...

  • Page 12: Setting Up The Software

    7. Setting up the software Please refer to the programming manual included in CD. CAUTION Antenna shall be mounted in such a manner to minimize the potential for human contact during normal operation. The antenna should not be contacted during operation to avoid the possibility of exceeding the FCC radio frequency exposure limit.
