Chapter 3
Overview
NOTE: In menus with numeric ranges of more than 50 numbers, hold down
Step
1
2
3
4
5
6
Figure 2. Moving within the Configuration Menu

Selecting A Menu Option

To select an option, you need to press the ↵ key. By default, however, the
↵ key is "locked" when the printer is turned on to prevent accidental changes
to the configuration menu. If you press the ↵ key when the key is locked, the
message "ENTER SWITCH LOCKED" displays on the LCD for one second
and the value will not be selected.
To unlock the ↵ key, press the ↓ and ↵ keys simultaneously. This toggles the
ENTER/LOCK function.
If this function is performed while the ↵ key is locked, the message
•
"ENTER SWITCH UNLOCKED" displays for one second, and the ↵ key
will be unlocked.
If this function is performed while the ↵ key is unlocked, the message
•
"ENTER SWITCH LOCKED" displays for one second, and the ↵ key will
be locked.
When you press the ↵ key (with the ↵ key unlocked), you select the value or
option that displays. An asterisk displays after the value you selected, and the
configuration is changed immediately.
86
the + or − key for more than 2 seconds to move through the range in
increments of 5. To move in increments of 1 again, release your hold
on the + or − key.
Press
OFFLINE
↓ ↵
ENTER SWITCH
&
UNLOCKED
. .
MENU MODE
.
QUICK SETUP
↓
Print Mode
UNTIL
Transfer*
+ –
Print Mode
or
Direct
↵
Print Mode
Direct*
LCD Notes
Allows you to make
configuration
changes.
Enables the printer
configuration menu.
Cycles through the
choices.
Selects the Direct
transfer mode.
