Printronix Guide Specification
RFID Label
915 MHz, 96 Bit, EPC Class 1, Gen 2
Rafsec Short Dipole Antenna
Applicable Printer Models
Print and Apply Models
SLPA8000r MP2
SLPA7000r MP2
Desktop Models
SL4M MP2
SL5000r MP2
Disclaimer
RFID Label Guide Specification
Gen 2, Rafsec Short Dipole Antenna
182316-000 Rev C
Page 1 of 5
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Printronix SL5000r MP2
Summary of Contents for Printronix SL5000r MP2
- Page 1 RFID labels, are provided by Printronix on an "as is" basis and without warranty of any kind whatsoever, expressed or implied. In particular, Printronix disclaims any implied warranty of merchantability or fitness for a particular purpose.
- Page 2 Rafsec Short Dipole Antenna 1. Scope 1.1. This document provides guide specifications for developing 96 Bit, EPC UHF Class 1, Gen 2, RFID labels with Rafsec Short Dipole Antenna for use with Printronix MP2 series of RFID printers. 1.2. Target Applications 1.2.1.
- Page 3 3.7.2. 4” Printer Models 3.7.2.1. Nominal label facestock width with inlay is 4.0" (101.6 mm). Maximum width of label construction supported by printer is 4.5" (114.3 mm) edge to edge (4.1" (104.1 mm) is printable). 3.7.3. 6” Printer Models RFID Label Guide Specification...
- Page 4 4.1.1. Wax resin ribbon for best durability. Wax Resin Blend Ribbon 8500, 4.33" x 2051' (110 mm x 625 m), package of 6 ribbons, Printronix part no. 203485-103. 4.1.2. General purpose wax ribbon. Wide Spectrum Wax Ribbon 8300, 4.33" x 2051' (110 mm x 625 m), package of 6 ribbons, Printronix part No.
- Page 5 Chip facing down, Minimum center slot back Pitch 2.0" Liner Corner radius: 0.125" typ. Printronix RFID Label Requirements for Rafsec Short Dipole Inlay Viewed from Facestock Side PRINTRONIX All Dimensions in Inches Figure 1. Label Layout Trailing edge of timing mark to leading edge 2.0625"...
