Levelflex FMP56, FMP57 HART
Endress+Hauser
299 (11.8)
 44 Dimensions. Unit of measurement mm (in)
Material
• Protection cap; 316L (1.4404)
• Bracket; 316L (1.4404)
• Angle bracket; 316L (1.4404)
• Clamping screw; 316L (1.4404) + carbon fiber
• Molded rubber part (4x); EPDM
• Screws; A4
• Disks; A4
• Ground terminal; A4, 316L (1.4404)
Order number for accessories:
71162242
16.1.2 Mounting bracket for electronics housing
With "remote sensor" device versions (feature 060 in the product structure), the mounting
bracket is included in the scope of delivery. It can be ordered as a separate accessory .
A
122 (4.8)
161 (6.34)
 45 Mounting bracket for electronics housing; unit: mm (in)
A Wall mounting
B Post mounting
B
ø42...60
(1.65...2.36)
127...140
(5...5.51)
162...175
(6.38...6.89)
Accessories
202 (7.95)
A0015472
A0014793
87
