Levelflex FMP56, FMP57 HART
Assign status
Navigation
Prerequisite
Description
Selection
Additional information
Assign limit
Navigation
Prerequisite
Description
Selection
Assign diagnostic behavior
Navigation
Prerequisite
Description
* Visibility depends on order options or device settings
Endress+Hauser
 Setup → Advanced setup → Switch output → Assign status
Switch output function (→  150) = Digital Output
Assigns a Discrete Output Block or an Advanced Diagnostic Block to the switch output.
• Off
• Digital output AD 1
• Digital output AD 2
The Digital output AD 1 and Digital output AD 2 options refer to the Advanced
Diagnostics Blocks. A switch signal generated in these blocks can be output via the switch
output.
 Setup → Advanced setup → Switch output → Assign limit
Switch output function (→  150) = Limit
Defines which process variable will be checked for limit violation.
• Off
• Level linearized
• Distance
*
• Interface linearized
*
• Interface distance
*
• Thickness upper layer
• Terminal voltage
• Electronic temperature
• Measured capacitance
• Relative echo amplitude
• Relative interface amplitude
• Absolute echo amplitude
• Absolute interface amplitude
 Setup → Advanced setup → Switch output → Assign diag. beh
Switch output function (→  150) = Diagnostic behavior
Defines to which behavior of diagnostic events the switch output reacts.
*
*
*
Operating menu



