Operating menu
Assign current output 1 to 2
Navigation
Description
Selection
Factory setting
Additional information
6) only for devices with two current outputs
146
"Current output 1 to 2" submenu
The Current output 2 submenu (→  146) is only available for devices with two
current outputs.
Navigation  Setup → Advanced setup → Curr.output 1 to 2
 Setup → Advanced setup → Curr.output 1 to 2 → Assign curr.
Select process variable for current output.
• Level linearized
• Distance
• Electronic temperature
• Relative echo amplitude
• Analog output adv. diagnostics 1
• Analog output adv. diagnostics 2
For level measurements
• Current output 1: Level linearized
6)
• Current output 2 : Level linearized
Definition of the current range for the process variables
Process variable
Level linearized
Distance
Electronic temperature
Relative echo amplitude
Analog output adv.
diagnostics 1/2
1) the 0% level is defined by Empty calibration parameter (→  114)
2) The 100% level is defined by Full calibration parameter (→  114)
It may be necessary to adjust the 4mA and 20mA values to the application (especially
in the case of the Analog output adv. diagnostics 1/2 option ).
This can be done by the following parameters:
• Expert → Output → Current output 1 to 2 → Turn down
• Expert → Output → Current output 1 to 2 → 4 mA value
• Expert → Output → Current output 1 to 2 → 20 mA value
4 mA value
1)
0 % or the associated
linearized value
0 (i.e. level is at the reference
point)
–50 °C (–58 °F)
0 mV
depending on the parametrization of the Advanced Diagnostics
Levelflex FMP56, FMP57 HART
20 mA value
2)
100 % or the associated linearized value
Empty calibration (→  114) (i.e. level is at
0 %)
100 °C (212 °F)
2 000 mV
