Levelflex FMP56, FMP57 HART

Endress+Hauser

 25

Pin assignment of M12 plug

1

Signal +

2

Not assigned

3

Signal -

4

Ground

 26

Pin assignment of 7/8" plug

1

Signal -

2

Signal +

3

Not assigned

4

Shielding

4

3

1

2

1

3

2

4

Electrical connection

A0011175

A0011176

41
