Levelflex FMP56, FMP57 HART
Distance
Navigation
Description
Additional information
Level linearized
Navigation
Description
Additional information
Output current 1 to 2
Navigation
Description
Endress+Hauser
17.5.4 "Measured values" submenu
Navigation  Diagnostics → Measured val.
 Diagnostics → Measured val. → Distance
Displays the measured distance D
or threaded connection) and the level.
 61 Distance for bulk solid measurements
The unit is defined in the Distance unit parameter (→  113).
 Diagnostics → Measured val. → Level linearized
Displays linearized level.
This unit is defined by the Unit after linearization parameter.
 Diagnostics → Measured val. → Output curr. 1 to 2
Shows the actual calculated value of the output current.
between the reference point (lower edge of the flange
L
D
L
Operating menu
A0013201
175
