Extended Status
Code (in hex)
0127 Invalid originator to target network connection size
0128 Invalid target to originator network connection size
0129 Invalid configuration application path
012A Invalid consuming application path
012B Invalid producing application path
012C Configuration symbol does not exist
012D Consuming symbol does not exist
012E Producing symbol does not exist
012F Inconsistent application path combination
0130 Inconsistent consume data format
0131 Inconsistent produce data format
0132 Null forward open function not supported
0133 Connection timeout multiplier not acceptable
0134 - 0202 Reserved
0203 Connection timed out
0204 Unconnected request timed out
0205 Parameter error in unconnected request service
0206 Message too large for unconnected_Send service
0207 Unconnected acknowledge without reply
0208 - 0300 Reserved
0301 No buffer memory available (Connection buffer memory shortage)
0302 Network bandwidth not available for data
0303 No consumed connection ID filter available
0304 Not configured to send scheduled priority data
0305 Schedule signature mismatch
0306 Schedule signature validation not possible
0307 - 0310 Reserved
0311 Port not available
0312 Link address not valid
0313 - 0314 Reserved
0315 Invalid segment in connection path
0316 Forward close service connection path mismatch
0317 Scheduling not specified
0318 Link address to self invalid
0319 Secondary resources unavailable
031A Rack connection already established
031B Module connection already established
Miscellaneous (This extended status is returned when no other extended status code applies for a
031C
connection related error.)
031D Redundant connection mismatch
031E No more user configurable link consumer resources available in the producing module
031F No user configurable link consumer resources configured in the producing module
0320 Connection is forbidden
0800 Network link in path to module is offline
0801 - 080F Reserved
Description of Status
89
(2/3)
