11-3. CIP General Status Code

The following table lists the Status Codes that may be present in the General Status Code field of an Error
Response message.
Note that the Extended Code Field is available for use in further describing any General Status Code. For the
Extended Status code, refer to "11-4.".
Codes in the gray area aren't available NCW-3DHIP.
General Status
Code (in hex)
00 Success
01 Connection failure
02 Resource unavailable
03 Invalid parameter value
04 Path segment error
05 Path destination unknown
06 Partial transfer
07 Connection lost
08 Service not supported
09 Invalid attribute value
0A Attribute list error
0B Already in requested mode/state
0C Object state conflict
0D Object already exists
0E Attribute not settable
0F Privilege violation
10 Device state conflict
11 Reply data too large
12 Fragmentation of a primitive value
13 Not enough data
14 Attribute not supported
15 Too much data
16 Object does not exist
Status Name
Service was successfully performed by the object specified.
A connection related service failed along the connection path.
Resources needed for the object to perform the requested service were
unavailable.
See Status Code 0x20, which is the preferred value to use for this
condition.
The path segment identifier or the segment syntax was not understood
by the processing node. Path processing shall stop when a path
segment error is encountered.
The path is referencing an object class, instance or structure element
that is not known or is not contained in the processing node. Path
processing shall stop when a path destination unknown error is
encountered.
Only part of the expected data was transferred.
The messaging connection was lost.
The requested service was not implemented or was not defined for this
Object Class/Instance.
Invalid attribute data detected.
An attribute in the Get_Attribute_List or Set_Attribute_List response has
a non-zero status.
The object is already in the mode/state being requested by the service.
The object cannot perform the requested service in its current
mode/state.
The requested instance of object to be created already exists.
A request to modify a nonmodifiable attribute was received.
A permission/privilege check failed.
The device's current mode/state prohibits the execution of the
requested service.
The data to be transmitted in the response buffer is larger than the
allocated response buffer.
The service specified an operation that is going to fragment a primitive
data value, i.e. half a REAL data type.
The service did not supply enough data to perform the specified
operation.
The attribute specified in the request is not supported.
The service supplied more data than was expected.
The object specified does not exist in the device.
Description of Status
85
(1/3)
