NSD Absocoder NCW-3DHIPV1R Specifications & Instruction Manual page 119

Instance Attribute (Class ID: 0x0F, Instance ID: 0x03)
ID Name
0x01 Parameter Value
0x02 Link Path Size
0x03 Link Path
0x04 Descriptor
0x05 Data Type
0x06 Data Size
0x07 Parameter Name String
0x08 Unit String
0x09 Help String
0x0A Minimum Value
0x0B Maximum Value
0x0C Default Value
0x0D Scaling Multiplier
0x0E Scaling Divisor
0x0F Scaling Base
0x10 Scaling Offset
0x11 Multiplier Link
0x12 Divisor Link
0x13 Base Link
0x14 Offset Link
0x15 Decimal Precision
Instance Attribute (Class ID: 0x0F, Instance ID: 0x04)
ID Name
0x01 Parameter Value
0x02 Link Path Size
0x03 Link Path
0x04 Descriptor
0x05 Data Type
0x06 Data Size
0x07 Parameter Name String
0x08 Unit String
0x09 Help String
0x0A Minimum Value
0x0B Maximum Value
0x0C Default Value
0x0D Scaling Multiplier
0x0E Scaling Divisor
0x0F Scaling Base
0x10 Scaling Offset
0x11 Multiplier Link
0x12 Divisor Link
0x13 Base Link
0x14 Offset Link
0x15 Decimal Precision
Access
Data Type
Get Set
○ ○ BOOL
○ USINT
－
Packed
○
－
EPATH
○ WORD
－
○ EPATH
－
○ USINT
－
SHORT_
○
－
STRING
SHORT_
○
－
STRING
SHORT_
○
－
STRING
○ BOOL
－
○ BOOL
－
○ BOOL
－
○ UINT
－
○ UINT
－
○ UINT
－
○ INT
－
○ UINT
－
○ UINT
－
○ UINT
－
○ UINT
－
○ USINT
－
Access
Data Type
Get Set
○ ○ DINT
○ USINT
－
Packed
○
－
EPATH
○ WORD
－
○ EPATH
－
○ USINT
－
SHORT_
○
－
STRING
SHORT_
○
－
STRING
SHORT_
○
－
STRING
○ DINT
－
○ DINT
－
○ DINT
－
○ UINT
－
○ UINT
－
○ UINT
－
○ INT
－
○ UINT
－
○ UINT
－
○ UINT
－
○ UINT
－
○ USINT
－
110
Description
Parameter value (Axis-1 parameter: Position Data
Increase Direction)
3
"20 64 24 01 30 0C"
0x0000
0xC1 (Logical boolean)
1
0x10,"Axis-1 Direction"
0x00,""
0x33,"Axis-1 Parameter - Position Data Increase
Direction"
0
1
0
1 (Scaling factor)
1 (Scaling factor)
1 (Scaling factor)
0 (Scaling factor)
0 (Scaling factor)
0 (Scaling factor)
0 (Scaling factor)
0 (Scaling factor)
0 (Number of decimal places of parameter value)
Description
Parameter value (Axis-1 parameter: Preset Value)
3
"20 64 24 01 30 13"
0x0000
0xC4 (Signed 32-bit integer)
4
0x10,"Axis-1 Preset Va"
0x00,""
0x1F,"Axis-1 Parameter - Preset Value"
0
16777215 (0x00FFFFFF)
0
1 (Scaling factor)
1 (Scaling factor)
1 (Scaling factor)
0 (Scaling factor)
0 (Scaling factor)
0 (Scaling factor)
0 (Scaling factor)
0 (Scaling factor)
0 (Number of decimal places of parameter value)
