NSD Absocoder NCW-3DHIPV1R Specifications & Instruction Manual page 135

ID Name
0x0A Interface Label
0x0B Interface Capability
Instance Service (Class ID: 0xF6, Instance ID: 0x01, 0x02)
ID Name
0x01 Get_Attribute_All
0x0E Get_Attribute_Single
Access
Data Type
Get Set
○ SHORT_
－
STING
○ Structure
－
DWORD
Structure
Read out all attribute values from NCW-3DHIP.
Read out one attribute value from NCW-3DHIP.
126
Description
identifier
Interface
Instance 0x01: "Port1"
Instance 0x02: "Port2"
Interface function
[Capability Bits]
The values (Bit0:0, Bit1:1, Bit2:1, and Bit3:0) are fixed.
Indicates interface functions other than Speed / Duplex.
Bit0: Manual Setting Requires Reset
Bit1: Auto-negotiate
Bit2: Auto-MDIX
Bit3: Manual Speed/Duplex
Bit4-31: Reserved
[Speed/Duplex Options]
A pair of Seed/Duplex supported by Interface Control
attributes
USINT [Speed/Duplex element number]
Fixed at 4
Structure [Speed/Duplex element 0]
[0]
UINT [Interface Speed]
Same contents as the Forced
Interface Speed of the
Interface Control Attribute
(Element 0): 10
USINT [Interface Duplex Mode]
0: Half Duplex
1: Full Duplex
2-255: Reserved
(Element 0):0
Structure [Speed/Duplex element 1]
[1]
UINT [Interface Speed]
(Element 1): 10
USINT [Interface Duplex Mode]
(Element 1): 1
Structure [Speed/Duplex element 2]
[2] UINT [Interface Speed]
(Element 2): 100
USINT [Interface Duplex Mode]
(Element 2): 0
Structure [Speed/Duplex element 3]
[3]
UINT [Interface Speed]
(Element 3): 100
USINT [Interface Duplex Mode]
(Element 3): 1
Description
(3/3)
