9-9. CIP Implicit Messaging (I/O Connection)

NCW-3DHIP has the "Exclusive-Owner Connection" for the unicast connection which can connect with the
real-time I/O communication connection. It lets control the I/O data of NCW-3DHIP.
The connection summary and data format are described below.

9-9-1. Exclusive-Owner Connection

(1) Connection Attribute
Transport Type
Transport Class
Production Trigger
Scanner -> Slave
(Output)
Slave -> Scanner
(Input)
Configuration
Connection Name
Help String
Connection Path
Item
Size
Realtime Transfer Format
Connection Type
Priority
RPI
Size
Realtime Transfer Format
Connection Type
Priority
RPI
Size
Client , Exclusive-Owner
1
Cyclic
16Byte
32bit Run/Idle Header
Point to Point
High
20ms (min.: 2ms, max.: 100ms)
28Byte
Modeless
Point to Point
High
20ms (min.: 2ms, max.: 100ms)
0Byte
"Input / Output / Configuration"
"Exclusive-Owner"
20 04 24 67 2C 66 2C 65
77
Description
