NSD Absocoder NCW-3DHIPV1R Specifications & Instruction Manual page 34

● In the case of using the commercially available cable (JKPEV-S 1.25mm
with a connector
ABSOCODER sensor
ABSOCODER sensor
Connector pin No.
and wire color
Pin Signal
Wire color
No. names
1 Brown SIN＋
2 Red SIN－
3 Orange
－COS＋
4 Yellow
－COS－
5 Green OUT＋
6 Blue OUT－
7
－ －
8
－ －
9
－ －
10
－ －
11 Shield
Shield
12
－ －
Cautions for the connection by the connector
1: The wire No. of JKPEV-S cable is printed on the surface of the white wire.
2: Unused wires of JKPEV-S cable should be severed at both ends.
*1: Both violet and gray wire aren't used.
Please install the connector
by customers
JKPEV-S Cable cross section
Commercially available cable
JKPEV-S cable
Connector pin No. and wire color
Pin Wire No. Wire
No. (pair) color
1
White
1
2
Black
3
White
2
4
Black
5
White
3
6
Black
7 4
White
8 (Not used)
Black
9
5
White
10 (Not used)
Black
11
Shield
12
－
25
×5P) and connecting
2
NSD special cable
Signal
names
SIN＋
SIN－
－COS＋
－COS－
OUT1＋
OUT1－
－
－
－
－
Shield
－
－
Converter
NSD special cable
Connector pin No.
and wire color
Pin Wire Signal
No. color names
1 SIN＋
Brown
2 SIN－
Red
3
Orange
－COS＋
4
Yellow
－COS－
5 OUT1＋
Green
6 OUT1－
Blue
7 OUT2＋
Violet *1
8 OUT2－
Gray *1
9
－
－
10
－
－
11 Shield
Shield
12
－
－
