APPENDIX 2-7. QoS Object (Class ID: 0x48)

The QoS object provides relative priority setting information of different transmission traffics.
A transmission traffic priority can be adjusted by a managed switch on the network when the relative priority is set.
The relative priority is specified by the Qos object attribute setting.
NCW-3DHIP uses DiffServ (QoS) (redefinition of the "ToS" field in IP head). Packets are classified by elements,
and priorities (64 steps) are defined for each group. The packet transmission is executed according to the
definition. (NCW-3DHIP doesn't support the 802.1Q tag.).
Note
Restart the power supply when settings are changed.
Following tables indicate specifications of the QoS object.
The QoS object has one instance.
Class Attribute (Class ID: 0x48)
ID Name
0x01 Revision
0x02 Max Instance
0x03 Number of Instances
Class Service (Class ID: 0x48, Instance ID: 0x00)
ID Name
0x0E Get_Attribute_Single
Access
Data Type
Get Set
○ UINT
－
○ UINT
－
○ UINT
－
Read out one attribute value from NCW-3DHIP.
116
Description
1
1
1
Description
